RRS LC-A10 Quick Start Manual

1146 Farmhouse Lane, San Luis Obispo,
California 93401 USA
1-805-528-6321 | 1-888-777-5557
www.ReallyRightStuff.com
TRIPOD LENS COLLAR
____________________________
COLLAR/PACKAGE ID
Collar: Includes collar only. Collar has ¼"-20 threaded hole at base
for direct mounting to tripod head with ¼"-20 threaded stud.
Collar + Foot Package: Includes collar + LCF-10 or LCF-11 foot. Foot
has dovetail for mounting in any Really Right Stuff-style clamp.
AVAILABLE MODELS:
LC-A10 ............................. Nikon AF-S 300mm f/4
LC-A11 .............................. Nikon AF 80-400mm f/4.5-5.6 VR
LC-A12 ................... Nikon AF-S 70-200mm f/4 VR
LC-A13 ........... Nikon AF-S 80-400mm f/4.5-5.6 VR
LC-A14 ....... Nikon AF-S 200-500mm f/5.6E ED VR
LENS COLLAR
COLLAR ONLY
SPECIFICATIONS:
LC-A10 Collar / LC-A10 Collar + LCF-10 Package ............. 4.6oz / 7.3oz
(lens first released 2000)
LC-A11 Collar / LC-A11 Collar + LCF-10 Package ............. 4.7oz / 7.4oz
(2005-2012)
LC-A12 Collar / LC-A12 Collar + LCF-10 Package ............. 3.5oz / 6.2oz
(lens first released 2012)
LC-A13 Collar / LC-A13 Collar + LCF-10 Package ............. 5.2oz / 7.9oz
(lens first released 2013)
LC-A14 Collar / LC-A14 Collar + LCF-11 Package ............. 5.1oz / 8.3oz
(lens first released 2016)
LENS COLLAR PACKAGE
COLLAR + FOOT
hinge (to open collar
for installation)
collar lock knob
¼"-20 threaded hole
foot lock knob
mini-dovetail mounts
to LCF-10/LCF-11
spring-loaded
release latch
LCF-10 or LCF-11 foot
included in all collar +
foot packages
