TFA-01 ULTRA POCKET 'POD

Specifications

Leg Positions (3) ........... 1ˢᵗ angle stop, 2ⁿᵈ angle stop, fully splayed
Load Capacity .............................................................. 15 lbs / 6.8kg
Platform Diameter .........................................................1.3" / 34mm
Stud ........................................................ ¼"-20 with ⅜"-16 Adapter
Folded Length with Stud .............................................5.8" / 147mm
Height at 1ˢᵗ Angle Stop ...............................................4.7" / 119mm
Height at 2ⁿᵈ Angle Stop ................................................3.3" / 84mm
Height Fully Splayed ......................................................1.5" / 37mm
Weight .......................................................................... 4.8 oz / 135g

KEY FEATURES

Black anodized apex is machined
from 6061-T6 aluminum. Internal
¼" - 20 stainless stud accepts
hardware is stainless steel.
tripod head or camera. Use
included adapter if head has
larger 3/8" socket.
Black anodized legs are
machined from 6061-T6
aluminum.
Use Torx keys
(included) to adjust leg
tension.
Pocket friendly size
when folded.
Wrap around rubberized
foot design assures positive
contact, even on curved
surfaces.
IN USE
Stainless steel adapter
(included)
1 SET ANGLE STOPS
Open tripod to 1st
Rubberized foot
position.
is secured with
stainless pin.
Maximum stability is
achieved when legs are
fully splayed.
4
SET LEG TENSION
Optimal leg tension is set at the
factory. For tighter leg tension,
seat T10 Torx keys (included)
into leg bolts and rotate
clockwise to tighten.
2 Swing leg inwards slightly.
3 Slide angle
stop button
down.
3
2
Swing leg out.
4
