FR 3608
Supplied Parts List
A Drawer Slide, left (cabinet, middle and drawer profile with integrated ECD).
B Drawer Slide, right (cabinet, middle and drawer profile with integrated ECD).
C Bottom Mount Brackets
D1 Connecting Bracket
D2 Connecting Bracket with slot
D3 Support profile, left
D4 Support profile, right
F Tray (1 piece).
G Wire Support (1piece).
Screws:
(g) M4 x 8mm, zinc
(h) M4 Nut, zinc
( i ) M4 x 8mm, zinc
( j ) No. 8 x 5/8 in., zinc
( n) Washer
34L (36 qt.)
Waste Basket
34L (36 qt.)
Waste Basket
Inside cabinet width
375–465
(14.75 –18.30)
Adjustable
10
Door Front Bracket
facing outward
134
102
70
38
6
0
96
(3.78)
64
(2.52)
mm
(in.)
FR 3608: 375 – 465
Inside cabinet width
Mounting Instructions
Figure 1
Adjustable
Door Front Bracket
facing inward
75
(2.05)
(14.76 –18.30)
mm
(in.)
FR 3608
FR 3608
1 of 3
