Communication Armest Mount
To Install:
Image below shows installed device.
Step 1: Assemble Receiver onto armrest by removing
armrest pad and placing the Receiver between the pad
and armrest tubing. Align the slots in the receiver to
the holes in the armrest tube and reattach the armrest
pad. Tighten bolts securely.
Receiver
Step 2: Slide Extender into Receiver and tighten knob.
Step 3: Attach Clamps and Extension Bar as shown
below. Tighten Knobs on clamps once desired position
is obtained.
Clamp
Extender
Extension
Bar
.
Page 1 OF 2 –08630
