TMS JAXX SOFA TABLE 52203 Assembly Instruction Manual

Hide thumbs
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Download this manual
DATE: 5/8/2016
Please refer and use this assembly instruction to assemble the product. Contact our
customer service department in case there are any missing or damage parts or hardware.

ASSEMBLY REQUIREMENTS:

2-Person
Assembly

ASSEMBLY PREPARATION

1. Remove all packaging materials, staples and packing straps from the carton.
2. Refer to Parts List and Hardware List and ensure they are complete before you start assembling.
3. Place all wooden parts on a clean, flat and soft surface (e.g. carpet or rug) to prevent parts from
getting scratched.
Thank you for purchasing our product!
Replacement parts are normally shipped within 2 or 3 days.
Email: replacementparts@buylateral.com
Within 30 days from delivery date
We appreciate your business!
2 Hours
Assembly Time
(Approximate)
SOFA TABLE ITEM# 52203
Tools Required:
(Not Provided)
Page 1 of
7
Phillips Screwdriver
Mallet
