AEC ILLUMINAZIONE ITALO 2 URBAN TP Mounting And Maintenance Instruction

ITALO 2_URBAN_TP_IM_ENG - Rev.04 of 27/10/14
M8 / 5/16 set screws
Hex key: 4mm / 5/32"
Twisting moment: 8Nm
Pic. 2
Release the set screw of
the bracket
A
MOUNTING AND MAINTENANCE
INSTRUCTION
TP mounting
ITALO 2 URBAN TP is provided with post-top attachment for
tenon with diameter of 60mm / 2-3/8" (Pic. 1).
Mount the fixture as indicated on Pic. 1.
Pic. 1
Electrical parts
Remove the cover as per instructions on Pic. 2 to Pic. 5.
To gain access to the electrical components, release the latch (A – Pic.
6) and lift the upper frame until the hinge is locked (Pic. 7).
Pic. 3
Pass the cable through the bracket, and
Remove the
then through the cable gland or the
cover
Pic. 6
MOUNTING AND MAINTENANCE
Pic. 4
membrane.
Page 1 of 4
B
Pic. 5
Put the cover back on and
fasten by set screw (B).
Hinge
Pic. 7
