Thorn TONPAK LED G2 Installation Instructions

TONPAK LED G2
1.Installation and commissioning may only be carried out by authorized specialists and wired in
accordance with the latest IEE electrical regulations or the national standards
2.Mains power must be switched off before carrying out installation
3.The manufacturer, shall not be liable for any damage resulting from inappropriate modifications to
the luminaire or faulty installation.
4.If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced
by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
5.Range mounting height 15m max.
6.Only installed outside the arm's reach.
7.Electronic controlgear for LED modules tc:85°C.
8.Caution.risk of electric shock
1.
2.
3.
4.
5.
6.
7.LED
8.
SAP Code
22666314 TONPAK LED G2 50W
22666315 TONPAK LED G2 75W
22666316 TONPAK LED G2 100W
22666317 TONPAK LED G2 150W
22666318 TONPAK LED G2 200W
1/2
IEE
15
tc:85
220-240V~ 50/60Hz
220-240V~ 50/60Hz
220-240V~ 50/60Hz
220-240V~ 50/60Hz
220-240V~ 50/60Hz
L1 (mm)
L2 (mm)
L1 L2 W
50W 273 285 67
75W 273 285 67
100W 273 285 67
366 394 72
150W
200W 366 394 72
W (mm)
H Weight Projected Area
349 4.5KG 0.08m²
349 4.5KG 0.08m²
349 4.5KG 0.08m²
456 6.6KG
0.14m²
456 6.6KG 0.14m²
