To insure proper installation in complete compliance with your warranty, we recommend installation by a professional installer.
Vertical LED Task Lights for Mirrored Cabinets
Congratulations on your purchase of Americas finest Accessories for Mirrored Cabinets by GlassCrafters, Inc.
World class engineering and state of the art design will enable you to enjoy your cabinet for many years to come.
We realize that the marketplace offers many choices and we thank you for selecting GlassCrafters for your Mirrored
Cabinet needs. The following instruction sheets are applicable for installation of this accessory on all Flat or Beveled
This accessory also may be added to any previously installed surface mounted GlassC rafters Mirrored Cabinet.
24" High
Vertical Task LED Lights
(Mirrored Cabinet Sold Separately)
Please use extreme care while unpacking and handling your GlassCrafters' Mirrored Cabinet Accessory.
Report any damage immediately to our GlassCrafters customer service team at 800-233-7362,
GLASSCRAFTERS, INC
193 Veterans Blvd., Carlstadt, NJ 07072
Installation Instructions
Frameless Mirror Cabinets, both 4" deep and 6" deep.
Patent Pending.
30" High
Vertical Task LED Lights
(Mirrored Cabinet Sold Separately)
Monday thru Friday from 8:00 am to 5:00 pm (EST)
1+(800) 233-7362 (F) 1+(888) 233-7362
sales@glasscraftersinc.com
This unit's electrical connections
must be made by a
Licensed Electrician in a
manner that conforms to the
National Electric Code.
36" High
Vertical Task LED Lights
(Mirrored Cabinet Sold Separately)
1
06/2016
Advertisement
Related Manuals for GlassCrafters GC1624
Summary of Contents for GlassCrafters GC1624
- Page 1 World class engineering and state of the art design will enable you to enjoy your cabinet for many years to come. We realize that the marketplace offers many choices and we thank you for selecting GlassCrafters for your Mirrored Cabinet needs. The following instruction sheets are applicable for installation of this accessory on all Flat or Beveled Frameless Mirror Cabinets, both 4”...
- Page 2 Installing Vertical LED Task Lights on: Tools Required for Installation -- Surface Mounted Cabinet, 4” & 6” deep ....6 & 7 GlassCrafters recommends the following tools to -- Recessed Cabinet, 4” deep........8 properly and safely install your Vertical lights on a -- Recessed Cabinet 6”...
- Page 3 Each installation package is supplied with two fixtures • 24” height sets are reversible for position, fits any width. • For 30” and 36” height left and right are clearly labeled in the package, fits any width. • Each Installation package comes with the two lights fully assembled with the cabinet connectors installed and two installation packages with parts as shown here.
- Page 4 VERTICAL LED TASK LIGHT Unpack all parts carefully and protect parts during installation. Standard Wiring Diagram from a Wall Switch WARNING IMPORTANT CIRCUIT SAFETY WALL SWITCH BREAKER WHITE 120 V AC INSTRUCTIONS BLACK 15 Amp To reduce the risk of electric shock, burns injury or fire follow these precautions: TO PREVENT SHOCK OR...
- Page 5 3 w/Vertical lights Width x Height Width x Height Width x Height Width x Height Width x Height Width x Height GC1624 14 3/8”x23 3/8” 19 1/8”x23 3/8” 29 3/8”x23 3/8” 34 1/8”x23 3/8” 44 3/8”x23 3/8” 49 1/8”x23 3/8”...
- Page 6 BEFORE WORKING ON WIRING. measured and marked location for the cabinet installation. NOTE: TAKE CARE IN HANDLING AND INSTALLING TO 2. Install the Glasscrafters, Inc. Mirrored Cabinet on the AVOID DAMAGE TO MIRRORS. ALWAYS PLACE THE finished surface following the manual instructions supplied MIRRORED CABINET ON A PADDED SURFACE TO with the cabinet.
- Page 7 Step 2, 3, 4 7. To replace the LED Mounting Panel, first reconnect the power cable from the 12V LED Drive Box to the LED Assembly. Hold the LED Mounting Panel in place and affix it using only the three stainless screws provided.
- Page 8 Vertical LED Task Lights for Recessed Mounted 4” Deep or 6” Deep Mirrored Cabinet FOR INSTALLATION OF A RECESSED MOUNTED CAB- INET BE SURE TO TURN OFF THE POWER AT THE SERVICE PANEL BEFORE WORKING ON WIRING. NOTE: TAKE CARE IN HANDLING AND INSTALLING TO AVOID DAMAGE TO MIRRORS.
- Page 9 e. Lift and tip the cabinet up and into position within the finished 6. To Install the fully assembled cabinet with the two light opening. Shim as need for level and plumb. fixtures recessed in the wall you must complete the wiring connections before reassembling the light fixtures.
- Page 10 Vertical LED Task Lights for Surface Mounted & Recessed 4” deep or 6” deep Mirrored Cabinet with Electric Option Surface Mounted Mirrored Cabinet with Electric Option-- FOR INSTALLATION OF A SURFACE MOUNTED OR RECESSED MOUNTED CABINET WITH ELECTRIC OPTION 30” high & 36” high (EO CABINET) BE SURE TO TURN OFF THE POWER AT THE SERVICE PANEL BEFORE WORKING ON WIRING.
- Page 11 OPTIONAL Side Mirror Kit Installation Side Mirror Kit parts list: For surface mounted 4” and 6” Mirrored Cabinets and semi-recessed 2 Mirror side panels to match the 6” Mirrored Cabinets. model height ordered 4 Side kit brackets with It is recommended to complete the wall Mounted installation adhesive tape before reassembling the Vertical Light Fixtures.
- Page 12 Damage to glass door during installation is not the of glass. responsibility of GlassCrafters Inc. and may result in loss of product warranty. When installing the cabinet door with VTL Lights fixed, becareful not to chip the door mirror. It is important to test the distance between the door’s glass edge and the...
- Page 13 Door Installation continued Step 1- Snap Hinge into place (CAUTION) Check adjustment 2) Lift and snap carefully to avoid door hitting Top into place and Bottom Light Cover Plates Inside Mirror Hinge Plate Door Frame 1) Insert into Outside Mirror Hinge Toe Cabinet first...
- Page 14 Step 3 - Hinge Adjustment: (CAUTION) Check door and adjustment carefully using the screw adjustmets on the hinge as shown. Left and right hinge adjustment is limited to 1/32” (1 mm). Test by closing the door with your hand behing the door to test the clearance to avoid door hitting Top and Bottom Light Cover Plates.
- Page 15 Limit Clips Limit Clips are provided should you need to re- duce the opening swing of the cabinet door from 170 degrees to 130 degrees (see top view) This will eliminate the possibility of the door hitting a wall sconce or other decorative items. Special adjustments of these clips is required with the Vertical Light Mirrored Cabinet.
- Page 16 GlassCrafters shall not be Prevailing state law on the limits of the implied warranty will apply.
