Summary of Contents for Russell Hobbs RH3VTD400
- Page 1 3kg Vented Tumble Dryer Instruction Manual Model number(s): RH3VTD400(B)(S) For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk PLEASE RET AIN...
-
Page 2: Table Of Contents
Contents Safety information ………………………………… 3 - 7 Before using your appliance ………………………………… Control panel ………………………………… 9 - 10 Installation ………………………………… 11 - 12 Operating instructions ………………………………… 13 - 16 Care and maintenance ………………………………… Trouble shooting ………………………………… 18-19 Technical specification ………………………………… Product fiche …………………………………... -
Page 3: Safety Information
Safety instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and... - Page 4 Safety instructions • Your machine is designed to be used domestically. Commercial use will cause your warranty to be cancelled. • Any tampering with the machine, except by a qualified engineer, in any way, will cause your warranty to be invalid. •...
- Page 5 Safety instructions • Under no circumstances should anything other than the recommended articles be placed in the tumble dryer. • The tumble dryer should be serviced by an appointed service team with genuine parts. Please contact the service team below for assistance with any repairs.
- Page 6 Safety instructions • Do not place items that have any type of oil soaked in to the fabric, in the tumble dryer. There is a potential the oil could catch on fire. • Fabric softeners, or similar products, should be used as specified by the fabric softener instructions.
- Page 7 Safety instructions • Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from escaping and so create a fire hazard.
-
Page 8: Before Using Your Appliance
Before using your appliance Before installation, check that all parts are present. If any parts are missing, please contact the product care service team on: 0345 208 8750. Feature Diagram Note: The drawings in the book may vary from your dryer. They are designed to show the different features of all models covered by this book. -
Page 9: Control Panel
Control Panel 1. On/Off Press the button to turn the dryer on and off 2. Extra Automatic drying for Cotton clothing (maximum load 3kg). Drying level: Extra dry. 3. Standard Automatic drying for Cotton and linen (maximum load 3kg ). Drying level: Standard dry. - Page 10 Control Panel 7. Refresh Refresh clothing or fabric (maximum load 1kg) 8. Start/pause button Press to start or pause the drying cycle. 9. Display Indicates the time remaining, child lock icon and filter cleaning reminder icon. Icons Child lock Shown on the display when the child lock has been activated, no actions can be carried out until the child lock is de-activated.
-
Page 11: Installation
Installation For convenience, dryers are often positioned close to the washing machine, so the laundry can be easily transferred. The dryer should be placed in a ventilated area with at least a 15cm distance from the wall. It is recommended that there are no obstacles within 1.5m in front of dryer. The tumble dryer will expel moist air, and it’s recommended this is directed outside to avoid condensation accumulating inside a room. - Page 12 Installation Fitting the vent hose One edge of the vent hose has a thread, this edge is to be aligned with the vent on the back of the appliance. When aligned, push and twist the end of the hose in a clockwise direction until the hose is attached securely. The air outlet hose must be extended directly to the outdoors.
-
Page 13: Operating Instructions
Operating Instructions IMPORTANT NOTE - If you are drying laundry that weighs less than 0.8kg (small loads) when wet, then select the Time function to dry clothes (minimum of 1 hour should be set). Remove all the packaging material, including any material inside the drum. Before using the appliance for the first time, it is advised to place two damp clothing articles inside the drum and dry them for 1 hour. - Page 14 Step 4 - Select the programme you require and press the Start/Pause button to start the drying cycle. The programme light will stay lit and the drum will begin rotating and will stop when the selected programme has finished. To change a programme that has already started, cancel the first programme by pausing and turning the machine off, before turning the machine back on to select the desired programme.
- Page 15 For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk...
- Page 16 Operating Instructions • Never tumble dry the following; Delicate items such as net curtains, woollen items, silk items, items with metal trims, nylon tights, bulky items such as blankets, or sleeping bags, feather quilts and items containing or including rubber foam. •...
-
Page 17: Care And Maintenance
Care and maintenance ALWAYS CLEAN THE FILTER AFTER EACH USE. Failure to do so could cause the safety cut-out to operate. - Pull the filter upwards from the appliance. - Open the filter and remove any threads or fluff by hand or with a soft brush. -
Page 18: Trouble Shooting
Trouble shooting Cause Solution Problem It is not plugged in Plug the machine in The fuse has blown Replace the fuse Your appliance does Electricity cut -off Check mains power not start. Start/pause button not pressed Press the Start/pause button The machine door is not completely closed Close the machine door If you are drying laundry that weighs less than... - Page 19 Trouble shooting Error code Cause Solution Temperature Stop the program, and reset the appliance by Sensor error unplugging the product for 1 minute. If the problem is not rectified after the product being plugged back in and powered then please call customer services.
-
Page 20: Technical Specification
Technical Specification Brand Russell Hobbs Model number RH3VTD400 (B) (S) Type Vented dryer Efficiency rating Capacity (KGs) Dimensions (CMs): (H)64.0 x (W)52.0 x (D)43.5 Product fiche Energy consumption 252.0 kWh per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. -
Page 21: Connection To Mains Supply
Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or coloured... -
Page 22: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 23: Notes
Notes: For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk... - Page 24 For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday – Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
