Mitchell Diagnostics MD-350 Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1
1. Vehicle Identification
Window
2. Camera
Front facing camera is 5MP.
3. Microphone
Front facing microphone.
4. Ambient Light Sensor
5. Main Screen Functions
6. Android Applications
Button
7. Camera Button
© Mitchell International, Inc.
2
MAIN MENU - Tap Below To Begin Your Diagnostic Experience
Select Vehicle
OBDII
Heavy Duty
Settings
Today is Tue, 12 Dec
13
12
11
23 22
21
20
19 18 17 16
8. Screen Shot Button
9. VCI Connection Manager
Button
10. Recent apps button
11. Power Button
12. Home Button
13. Back Button
14. Speaker
15. Power port
16. HDMI Port
17. Docking Station Port
MD-350 Quick Start Guide
3
4
10:08
Saved Diagnostic Data
Browser
MD-350
10
9
8
15 14
25
26
18. USB Type "A" port
19. Audio port
20. Ethernet Connector
21. VCI Port
22. Mini USB
23. Speaker
24. Microphone
Rear Facing Microphone.
25. Camera
Rear Facing Camera is 5MP.
26. Light
581063 Rev B | APDMD35033018
5
6
7
24
