the fit-and-fold booster
For Children 15 to 45kg
This hifold booster seat is for use from 15
to 45kg (33 to 100lbs.).
The hifold is approved to UN ECE R44/04
as a Group 2-3 booster seat with a weight
range of 15 to 36kg.
The hifold has been successfully tested for use by
children weighing 45kg (100lbs.) or less.
USA: Approved to FMVSS 213
This child restraint conforms to all applicable
Federal motor vehicle safety standards for use in
motor vehicles.
EN
TM
Model Number:
•
HF01-GB
•
HF02-GB
Important: Please Read this Manual!
KEEP THESE INSTRUCTIONS FOR
FUTURE USE. Store under Seat Base Cover.
MUST be used with a 3-point vehicle lap and
shoulder belt compliant with ECE R16 or
equivalent standard in other countries.
Child restraint laws vary from country to
country. Check your local laws as they may
have specific use requirements.
Advertisement
Table of Contents
Related Manuals for hifold Fit-and-fold booster HF01-GB
Summary of Contents for hifold Fit-and-fold booster HF01-GB
- Page 1 For Children 15 to 45kg Model Number: • This hifold booster seat is for use from 15 HF01-GB • to 45kg (33 to 100lbs.). HF02-GB Important: Please Read this Manual! The hifold is approved to UN ECE R44/04...
-
Page 2: Table Of Contents
Instruction Manual Storage Instruction Manual Storage........1 Instruction Manual Storage: Weight and Height Use Recommendations....1 Store instruction manual under Seat Base Cover. hifold Booster Seat Parts..........2 Warnings..............3 Selecting a Vehicle Seating Location.......4 Preparing for Use.............5 Initial Setup...............5 Adjusting the Size to Fit Your Child......6 Installation and Securing Your Child......7... -
Page 3: Hifold Booster Seat Parts
Booster Seat Parts Headrest Headrest Adjustment Headrest Side Cover Headrest Cover Adjustment Lock Height Adjustment Lever (Under Headrest Adjustment Cover) Headrest Headrest Side Headrest Side Fold Headrest Side Fold Lock Side Lock Shoulder Belt Guide Seat Back Shoulder Seat Back... -
Page 4: Warnings
• Check the position of the hifold booster and vehicle belt to avoid them becoming trapped by a movable seat or in a door of the vehicle during Model Number and everyday use. -
Page 5: Selecting A Vehicle Seating Location
Cover the seat when left in the sun. • NEVER use the hifold Booster Seat in a vehicle seating location with an active frontal air bag. If in doubt refer to vehicle manual. -
Page 6: Preparing For Use
In preparing the hifold for use with your child, you stable and locked will need to adjust the height and width of the hifold to fit your child by following the steps in this section. CAUTION: There are many folded and hinged elements. -
Page 7: Adjusting The Size To Fit Your Child
Adjusting the Size to Fit Your Child Headrest Sides - Press the Adjust the hifold Booster to the maximum button at the top of the height and maximum width as described below. headrest and move the side panels outwards a. Seat Base Sides/Lap... -
Page 8: Installation And Securing Your Child
Installation and Securing Your Child Sit child on the Booster Adjust the width of the Seat with child’s lower and Headrest Sides so they upper back in contact with are close to child’s head. the Seat Back, not slouching See instructions in down on the Seat Base with “Preparing for Use”... - Page 9 Make sure the belts are not twisted. hifold Adjust the height of the Check that vehicle lap belt Headrest to position the...
-
Page 10: Removing Your Child
Transportation and Storage: Lift the fabric flap found in the center of the back rest The hifold Booster Seat folds into a compact size for just below the headrest easy storage when not in use. Grip the lever and rotate... - Page 11 Folding the hifold Booster Seat . Fold Seat Back Sides - . Fold Headrest - Pinch Press button on Seat Back Fold Headrest Tabs together Lock, push down on Fold Lock rotate Headrest backwards and rotate Seat Back Side inwards .
-
Page 12: Additional Information
Additional Information Removal and Cleaning of Seat Cover • Care and Cleaning: Aircraft Use - This restraint is not certified for use in aircraft. Seat Covers (need to be removed prior to washing): Fabric seat covers are machine washable in cold water, delicate or gentle cycle. No bleach. Line Warning: dry. - Page 13 Removal and Cleaning of Seat Cover To remove seat covers for cleaning: Removal of Seat Back Cover: • Note: The cover is made up of three sections, Similar to the headrest one headrest, one backrest and one base cover, remove the side section.
-
Page 14: Customer Service Information
Removal and Cleaning of Seat Cover Customer Service Contact Information Removal of Seat Base Cover: Carfoldio Ltd. Unit 2407, PO Box 6945, • Remove Seat Base Side London, W1A 6US, England, U.K. covers first by pealing the Tel: 0800 4714984 (from within the U.K.) edge of the side section Tel: +44 207 866 2385 (International) away from the inner foam. -
Page 15: Warranty
Additional Information Warranty: For warranty service: At Carfoldio, we make innovative, high quality e-mail: support@mifold.co.uk products for children. We warrant this product to Tel: 0800 4714984 (from within the U.K.) be free from defects in material and workmanship Tel: +44 207 866 2385 (International) existing at the time of manufacture for a period of two years from the date of initial purchase (sales or write to: Carfoldio Ltd. -
Page 16: Instructions
• KEEP THESE INSTRUCTIONS FOR FUTURE use in aircraft. USE. Store under Seat Bottom Cover. Instruction Manual Carfoldio and hifold Manufactured and distributed By: Made in China ™ ® are registered trademarks Carfoldio Ltd. © 2019 Carfoldio Ltd.
