Canterbury - 5Ft Bed
Assembly Instructions
- Please keep for future reference
532/6662
Dimensions
Width - 171.6cm
Depth - 212.8cm
Height - 110cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
71943 Version A Date 10/06/2016

Advertisement

loading
Need help?

Need help?

Do you have a question about the Canterbury 5Ft Bed 532/6662 and is the answer not in the manual?

Questions and answers

Summary of Contents for TVILUM Canterbury 5Ft Bed 532/6662

  • Page 1 Canterbury - 5Ft Bed Assembly Instructions - Please keep for future reference 532/6662 Dimensions Width - 171.6cm Depth - 212.8cm Height - 110cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 71943 Version A Date 10/06/2016...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly, do not stand • We do not components and tools listed on or put weight on the product, recommend the use the following pages.
  • Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below 98008 Slats (153.6 x 200cm) 76181 Headboard (163.8 x 105cm) 18979 Rail (202 x 6.4cm) C 76180 Footboard (163.8 x 62cm) 65842 Leg...
  • Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. 10901 20209 13424 Self-adhesive Covercap x 4 Dowel (ø8x30mm) x 18 Bracket (61x50x37mm) x 2...
  • Page 5 Assembly Instructions Step 1 Fittings you will need for this step: # 15018 Insert dowel and bracket # 20209 Position side panel as in picture. Place bracket 15018 in large holes and press dowel into hole 20209 on the end edge of side panel NB .
  • Page 6 Assembly Instructions Step 3 Fittings you will need for this step: Insert dowel and cam # 20209 # 31643 Press dowel 20209 edge of headboard and footboard Place cam 31643 large holes of headboard and footboard. Arrow facing the edge of the panel.
  • Page 7 Assembly Instructions Step 5 Fittings you will need for this step: Attach bracket # 15020 Attach bracket 15020 into bushing. Step 6 Fittings you will need for this step: Insert cam bolts # 31513 Screw the cam bolt 31513 in the top molding D .
  • Page 8 Assembly Instructions Step 7 Fittings you will need for this step: Attach side panels # 15019 Align side panel NB with footboard C . Place side panel ends with dowels into the holes on footboard C . Insert screw 15019 to attach side panel NB with footboard C .
  • Page 9 Assembly Instructions Attaching headboard Step 9 Fittings you will need for this step: # 73826 # 26066 # 13424 NB ! Slats in top position # 26060 Attach rail 73826 on side panel NB in top position with screw 26066 . Place bracket 13424 with screw 26060 on headboard B and foot-...
  • Page 10 Assembly Instructions Step 10 Fittings you will need for this step: # 73826 # 26066 # 13424 # 26060 NB ! Slats in low position Attach rail 73826 on side panel NB in low position with screw 26066 . Place bracket 13424 with screw 26060 on headboard B and foot- board C .
  • Page 11 Assembly Instructions Step 11 Fittings you will need for this step: NB ! Slats in top position # 26060 Attach rail E with screw 26060 . Step 12 Fittings you will need for this step: # 26060 NB ! Slats in low position Attach rail E with screw 26060 .
  • Page 12 Assembly Instructions Step 13 Attach Top molding Place Top molding D onto top panel as shown. Tighten cams.
  • Page 13 Assembly Instructions Step 14 Fittings you will need for this step: # 94057 # 21204 # 26214 # 25420 Safety bracket 94057 to avoid slats and box mattress faling down. Attach safety bracket with nut 94057 21204 screw . Use screw 26214 to fi...
  • Page 14 Assembly Instructions Step 15 Fittings you will need for this step: # 10901 Attach covercap Fix covercap 10901 the footboard to cover the cam holes. Step 16 Fittings you will need for this step: NB ! Bed with slats # 26270 # 22021 Attach bushing with screw on rail...
  • Page 15 Assembly Instructions Step 17 Fittings you will need for this step: NB ! Bed with solid # 94202 bottom Use wedges to fi x solid bottom, see assembly instruction in bag 94202 Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
