Toto Clean Dry HDR100 GY Installation Manual

INSTALLATION MANUAL
Important Safeguards
(For your safety, please follow the instructions below.)
In this Instruction Manual, the following symbols are shown for safe and proper use
of your automatic faucet and in order to alert you to the possibility of personal injury
and damage to your property.
The symbols and their meanings are as follows.
Ignoring these symbols may cause
Warning
personal injury and/or property damage.
Ignoring these symbols may cause
Caution
severe injury and/or property damage.
*Some models may have different components from the ones illustrated below.
Do not install the unit in the places where corrosive
or combustible gas can be present.
This may cause product failure or damage.
Do not
Never attempt to disassemble for repair or
modification.
This may cause electric shock, fire, injury or failure
Do not
disassemble
Do not install outdoors or where it is exposed to
water.
This may cause current leakage, electric shock, fire, or failure.
Do not use in
humid area
0GU3040 2008.04
Warning
It is recommended to install a circuit-breaker in the power supply
Failure to do this may cause electric shock during overload or short
Important
circuit.
The chassis assembly must be installed on a smooth and even
wall surface which has enough strength.
Important
Failure to do this may cause damage or personal injury if it falls down.
Do not place anything beneath the unit; leave a clearance
of 3-15/16" (100mm). Do not install on uneven wall surface.
If air flow is not good, the product may not perform well .
Do not!
Specification
Product HDR100#GY
Power Rating 120V AC, 4.25 Amps, 60 Hz, 510 W
Power Connection Hardwiring
Power Saving Function Automatically turns OFF after 60 seconds of use
Decibel Rating
62 dB
Air Speed
224 mph (100 meters/second)
Dry Time
12 seconds
Drain Tray Capacity
0.20 gal (700 ml)
Ambient temperature 32°-104°F (0°-40°C)
Size 9-5/8" x 18-1/2" x 6-5/16"
10 lbs (4.5kg)
Weight
Clean Dry™
High Speed Hand Dryer
Warning
Caution
Notice
