Owner s Manual
Owner
Owner
CAUTION!
Read All Instructions Care-
fully Before Starting The In-
stallation or Operating This
Heater.
SAVE THIS MANUAL FOR FUTURE REFERENCE
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE
YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
S
C
U
S
s Manual
s Manual
s Manual
s Manual
Logwood 1261
EPA EXEMPT PER
METHOD 28A
TESTED TO
UL 1482
UNITED STATES STOVE COMPANY
227 Industrial Park Road
P.O. Box 151
South Pittsburg, TN 37380
(423) 837-2100
DO NOT USE THIS HEATER
IN A MOBILE HOME OR TRAILER
U S
R
85029E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for USSC Logwood 1261
Summary of Contents for USSC Logwood 1261
- Page 1 SAVE THIS MANUAL FOR FUTURE REFERENCE THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE. UNITED STATES STOVE COMPANY s Manual s Manual...
-
Page 2: Tools And Materials Needed
You've purchased a heater from North America's oldest manufacturer of wood burning products. By heating with wood you're helping to CONSERVE ENERGY! Wood is our only Renewable Energy Resource. Please do your part to preserve our wood supply. Plant at least one tree each year. Future generations will thank you. Tools and Materials Needed TOOLS Pencil... -
Page 3: Safety Rules
Safety Rules SAFETY NOTICE: If this heater is not properly installed a house fire may result. For your safety, follow the installation directions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. Read these rules and the instructions carefully. Check with local codes. -
Page 4: Installation
Installation Place the heater on solid masonry or solid concrete. When the heater is used on a combustible floor, use an Underwrit- ers Listed floor protector. The floor protector must comply with UL Standards. The base should extend at least 16" beyond the door side of the heater and should extend under the flue pipe if it is elbowed towards a wall. -
Page 5: Operation Of The Heater
Operation of the Heater BE SURE TO PUT A LAYER OF SAND OR FIREBRICK APPROXIMATELY 1 1/2" THICK IN THE BOTTOM OF THE STOVE BEFORE STARTING FIRE. Burn wood or wood products only. The wood should be air dried for at least six months prior to use for maximum efficiency. After the fire has been started and is burning satisfactorily, adjust the rate of burning by opening or closing the draft damper wheel on the feed door. - Page 6 CONNECTION OF CHIMNEY CONNECTOR TO A MASONRY CHIMNEY THROUGH A COMBUSTIBLE WALL Figure 8 shows how to connect the chimney connector of a heater to a masonry chimney through a combustible wall. There are five allowable ways that a chimney connector can be connected to a masonry chimney by passing through a combustible wall.
- Page 7 PART A, FIGURE 8 (FIGURE 8 CONTINUED ON NEXT PAGE) MINIMUM 12 IN. TO COMBUSTIBLES 1. Use a minimum 3-1/2" thick brick masonry wall framed into the combustible wall. A fireclay liner (ASTM C315 or equivalent) having a 5/8" minimum wall thickness must be used and it must be at least 12" away from any material that could catch fire.
- Page 8 PART B FIGURE 8 - (FIGURE 8 CONTINUED) PART C FIGURE 8 TWO VENTILATED AIR CHANNELS EACH 1 INCH. CONSTRUCTED OF SHEET STEEL. PART D FIGURE 8 PART E - (Figure 8) In addition to the methods shown by A, B, C, and D of Figure 8, a listed factory-built wall pass-through system may be purchased and installed according to the instructions packaged with it to provide a safe method of passing chimney connector through a combustible wall for a connection to a masonry chimney.
-
Page 9: Service Hints
WARNING! NEVER STORE FLAMMABLE LIQUIDS, ESPECIALLY GASOLINE. IN THE VICINITY OF THE HEATER. CAUTION! OVERFIRING THE APPLIANCE MAY CAUSE A HOUSE FIRE. IF A UNIT OR CHIMNEY CONNECTOR GLOWS, YOU ARE OVERFIRING. WARNING! NEVER OPERATE THIS HEATER WITH THE FUEL DOOR OPEN. WARNING! USE ONLY THE LEGS PROVIDED WITH THIS HEATER. - Page 10 Model 1261 Repair Parts PART NO. DESCRIPTION 40296 REAR LEG 40318 FRONT LEG 40297 MAIN BOTTOM 40298 MAIN SIDE 40299 MAIN BACK 40300 HEARTH PLATE 40301 SLIDING DRAFT PLATE 40302 DOOR FRAME 40303 40304 MAIN TOP 40305 PIVOTING TOP 40306...
- Page 11 NOTES...
-
Page 12: How To Order Repair Parts
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION AS SHOWN IN THIS LIST: UNITED STATES STOVE COMPANY 1. The PART NUMBER 2. The PART DESCRIPTION 3. The MODEL NUMBER: 1261 4. The SERIAL NUMBER: 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (423) 837-2100 www.USSTOVE.com...
