HOW TO ORDER REPAIR PARTS
This manual will help you to obtain efficient, dependable service
from the heater, and enable you to order repair parts correctly.
Keep this manual in a safe place for future reference.
When writing, always give the full model number which is on the
nameplate attached to the inside of the cabinet door of the
heater.
When ordering repair parts or options, always
give the following information as shown in the list:
1. The PART NUMBER
2. The PART DESCRIPTION
3. The MODEL NUMBER: 2927
4. The SERIAL NUMBER:________________
Before installing your heater, fill in the serial number of your
heater in the space provided above.
United States Stove Company
P.O.Box 151
227 Industrial Park Rd.
South Pittsburg, TN 37380
(423) 837-2100
Owners Manual
Model 2927
WONDERCOAL
AUTOMATIC COAL BURNING CIRCULATOR HEATER
*ASSEMBLY
*INSTALLATION
*OPERATION
*REPAIR PARTS
SAFETY NOTICE:
If this heater is not properly installed, a house fire may result.
For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
inspection requirements in your area.
CAUTION:
Read all instructions carefully before starting the installation
or operation of this heater.
Improper installation may void your warranty.
DO NOT USE THIS HEATER IN A MOBILE HOME OR TRAILER
United States Stove Company
P.O.Box 151
227 Industrial Park Rd.
S
C
U
S
South Pittsburg, TN 37380
(423) 837-2100
WARNOCK HERSEY
R
85761C 1/95
Advertisement
Table of Contents
Related Manuals for USSC Wondercoal 2927
Summary of Contents for USSC Wondercoal 2927
-
Page 1: How To Order Repair Parts
1. The PART NUMBER 2. The PART DESCRIPTION 3. The MODEL NUMBER: 2927 4. The SERIAL NUMBER:________________ Before installing your heater, fill in the serial number of your heater in the space provided above. -
Page 2: Fig.
Floor Protector Material: 3' x 4'-6" as specified on page 4. Furnace Cement (Manufacturer recommends: Rutland Code 78 or Equivalent) CIRCULATOR DIMENSIONS Fig. 1 32 1/4 16 1/8 33 1/2 4 1/8 MATERIALS 19 1/4 8 5/16 Options for Wondercoal Circulator Model 2927 F36 Blower... -
Page 3: Heater
RULES FOR SAFE INSTALLATION AND OPERATION Read these rules and the instructions carefully. SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For your safety, follow the installation directions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. -
Page 4: Table Of Contents
NON-COMBUSTIBLE CONSTRUCTION IN ACCORDANCE WITH NFPA 211 NOTE: DASHED LINES SHOW STRAIGHT UP AND THROUGH THE WALL INSTALLATION REPAIR PARTS LIST - MODEL 2927 (SEE PAGE 18) AUTOMATIC COAL BURNING CIRCULATOR Key No. Description Shaker Ash Pan Base Draft Damper Hinge Pin... -
Page 5: Chimney Connection
Secondarily, though, the chimney provides "Draft" which allows oxygen to be continuously introduced into the appliance, so that proper combustion is possible. As of April 1, 1987, all heaters and furnaces manufactured by United States Stove Company should be installed using a factory built chimney that meets the "Type HT"... -
Page 6: Repair Parts
CAUTION: tion. NOT ALL FIREPLACES ARE SUITABLE FOR INSTALLATION OF A COAL HEATER. REPAIR PARTS AUTOMATIC COAL BURNING CIRCULATOR HEATER MODEL NUMBER 2927 (SEE PAGE 16) REPAIR PARTS LIST KEY NO. PART NO. DESCRIPTION 89411 Mesh Brass Trim (LH/RH) 89410... - Page 7 INSTRUCTIONS FOR TWO-STEP LATCH OPERATION 1. Follow these instructions to operate you unit safely when operating the feed door. 2. Turn handle clockwise to the 12 o'clock position, pull the door open until you engage the second step (Fig. 11). 3.
-
Page 8: Service Hints
Most masonry chimneys have a cleanout. If yours does, make sure it is gasketed or otherwise sealed. A loose fitting door will contribute greatly to the draft problems. If you have any question regarding venting your appliance, feel free to contact the factory at the address and phone number on this Owner's Manual. -
Page 9: Shaker
This draft wheel may be adjusted to give the best performance depending on the particular needs of the user. TROUBLE SHOOTING TIPS FOR MODEL 2927 LIST OF PROBLEMS POSSIBLE CAUSE 1. -
Page 10: Flue Collar 1
3. Shake Grates vigorously back and OPERATING INSTRUC- forth to dump ashes into ash pan. Do TIONS this at least once every 12 hours of FUEL operation. Egg size Bituminous coal for residential 4. Empty ash pan regularly. Do not furnaces, or any of the specially pack- allow ashes to build up to grate, as grate aged fireplaces coals can be used.
