- Page 1 RS485-ETHERNET Interface v.1.1 INTRE CODE: Edition: 3 from 03.11.2014 Supercedes edition: 2 from 05.12.2013...
-
Page 2: Table Of Contents
INTRE TABLE OF CONTENTS 1. General description..........................3 2. Components arrangement........................3 3. Installation............................. 4 Basic guidelines................................4 Connection to the RS485 bus............................4 Connection to the Ethernet network..........................4 Installation of the interface............................... 5 4. -
Page 3: General Description
INTRE PSU features: Operation in the ETHERNET network via the RJ45 connector complaint with the IEEE 802.3 standard transmission speed 10/100Mbps full duplex or half-duplex mode (auto-negotiation) assigning a static or dynamic IP address (DHCP server) ... -
Page 4: Installation
INTRE 3. Installation. 3.1 Basic guidelines. When installing the RS485-ETHERNET interface, please follow the general rules that will help to avoid electromagnetic interferences and incorrect operation of the device: - supply the interface with the power source of low ripple voltage... -
Page 5: Installation Of The Interface
INTRE 3.4 Installation of the interface. 1. Lead the cable of the RS485 bus through the cable gland and the appropriate hole in the enclosure and then connect to the RS485 connector of the interface. The A+, B- cables should be connected the same way as the rest of devices (A+ to A+, B- to B-) In the case of shielded wires, the shield should be connected to the SG signal ground terminal. -
Page 6: Configuration Of The Rs485-Ethernet Interface
INTRE 4. Configuration of the RS485-Ethernet interface. 4.1 Introductory information. Ethernet interface parameters can be configured to adjust them to the intended operation mode. The configuration is done with „Configuration Tool” program. Download and install the "Configuration Tool" program available on: http://www.pulsar.pl/pliki/ConfigurationTool.msi... -
Page 7: Step 2 - Interface Network Search
For proper IP address change, it is recommended to turn off the firewall of the antivirus program for the time of configuration process. Run the „Configuration Tool” program. Make sure that the Ethernet-RS485 INTRE module is powered and connected to the router with a network cable. - Page 8 Fig. 5. Window of the „ Configuration Tool” program – the MAC address of the interface is selected. The MAC address of the Ethernet INTRE interface is located on a sticker below the bar code as a 12 digit number.
-
Page 9: Step 3 - Setting The Network Address - The „Network" Tab
INTRE 4.4 STEP 3 – Setting the network address – the „Network” tab. Start the configuration with setting the IP address, allowing data communication in an Ethernet network. Enter the settings in the „Network” tab. Fig. 7. The network settings window. -
Page 10: Step 4 - Setting The Serial Port Parameters - The "Serial" Tab
INTRE 4.5 STEP 4 – Setting the serial port parameters – the “Serial” tab. In the "Serial" tab, set the parameters responsible for the communication between Ethernet interface and the PSU as shown in the picture below. Fig. 8. The settings of the serial port communication parameters. -
Page 11: Step 5 - Additional Settings - The "Options" Tab
INTRE 4.6 STEP 5 – Additional settings – the "Options" tab. n the additional options tab, enter the idle time, after which the interface releases the network connection, in the "Timer Interval" field. By default, this time is set to 30 seconds. -
Page 12: The Connection Scheme In The Lan / Wan Network
INTRE 4.8 The connection scheme in the LAN / WAN network. 4.8.1 LAN network communication: Schematic diagram of LAN communication is shown in the figure below. Fig.10. The schematic diagram of LAN communication system. The topology of the network is based on an Ethernet switch (e.g. switch, router) connected to another PSU segments (connected in the RS485 bus) via the RS485-Ethernet interface. -
Page 13: Wan Network Communication
INTRE 4.8.2 WAN network communication: The communication between the PC and the final PSU is via the Internet using the public IP address of the router connected to the interface. Data from the router is redirected to the RS485-Ethernet interface, connected to the RS485 bus, and then forwarded to the PSU on the basis of the bus address. -
Page 14: Configuration Of Power Supplies
INTRE 5. Configuration of power supplies The communication in the RS485 bus requires setting appropriate communication parameters in all devices and assigning of unique addresses. The configuration of power supplies of the PSBEN series uses a display located on the front panel of the enclosure. Depending on the display type - LED or LCD - the procedure for changing the settings is different. -
Page 15: Setting The Transmission Parameters
INTRE 5.1.2 Setting the transmission parameters To enter the setup mode, press the „SET” button from the main screen ”. use the „<” or „>” buttons to display the menu - press the „SET” button - use the „<” or „>” buttons to display the Transmission menu (The Transmission menu is at the bottom of the screen) - press the „SET”... -
Page 16: Configuration Of Power Supplies Of The Psben Series With Led Display
INTRE 5.2 Configuration of power supplies of the PSBEN series with LED display The PSU fitted with LED display enables setting the communication parameters of the serial port from the LED panel. To enter the setup mode, simultaneously press the „<,>” rightmost and leftmost buttons on the LED panel. -
Page 17: Setting The Transmission Speed And Parity Of The Transmission
INTRE 5.2.2 Setting the transmission speed and parity of the transmission - simultaneously press the „<,>” rightmost and leftmost buttons - The „tSt” parameter will be displayed - press the right arrow „>” - the „trS” parameter will be displayed - press „OK”... -
Page 18: Configuration Of Power Supplies Of The En54 Series With Lcd Display
INTRE 5.3 Configuration of power supplies of the EN54 series with LCD display 5.3.1 Setting the communication address The PSU fitted with LED display enables setting the communication parameters of the serial port from the LED panel. To enter the setup mode, simultaneously press the „<,>” rightmost and leftmost buttons on the LED panel. -
Page 19: Setting The Transmission Parameters
INTRE 5.3.2 Setting the transmission parameters use the „>” or „<” buttons to display the menu - press the „SET” button - use the „>” or „<” buttons to display the Transmission menu (The Transmission menu is at the bottom of the screen) - press the „SET”... -
Page 20: Configuration Of Power Supplies Of The En54 Series With Led Display
INTRE 5.4 Configuration of power supplies of the EN54 series with LED display The PSU fitted with LED display enables setting the communication parameters of the serial port from the LED panel. To enter the setup mode, simultaneously press the „<,>” rightmost and leftmost buttons on the LED panel. -
Page 21: Setting The Transmission Speed
INTRE 5.4.2 Setting the transmission speed - simultaneously press the „<,>” rightmost and leftmost buttons - The „tSt” parameter will be displayed - press the right arrow „>” - The „trS” parameter will be displayed - press „OK” - The information about the selected transmission speed will be displayed - use the „<”... -
Page 22: Configuring The Connection In Powersecurity Program
INTRE 6. Configuring the connection in PowerSecurity program. For further configuration, the PowerSecurity program is required. The program is available on: http://www.pulsar.pl/pliki/PowerSecurity.exe It is an executable file, which does not require installation. 1) Save to disk and start the downloaded PowerSecurity.exe. -
Page 23: Technical Parameters
INTRE remote desktop of PSU EN54 remote desktop of PSU PSBEN menu bar manager window Fig. 13. Windows of the remote displays of the power supplies of the PSBEN (left) and EN54 series (right). 7. Technical parameters. 10 ÷ 30V DC... - Page 24 Directive, waste electrical and electronic equipment should be disposed of separately from normal household waste. Pulsar WARRANTY Siedlec 150, 32-744 Łapczyca, Poland Pulsar (the manufacturer) grants a five-year quality warranty for Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 the equipment, starting from the production date E-mail: biuro@pulsar.pl, sales@pulsar.pl...
