1. Technical description.

1.1. General description.

Stabilised DC power supply is intended for cameras installed in CCTV industrial systems. The unit has a
cable with a DC5.5/2.1 pin. When connected to fuse blocks of the LB4/xx/xx or LB8/xx/xx family, the power supply
unit can feed more cameras (max. 4 or 8). The unit is protected against short-circuit and overload.

1.2. Technical parameters.

Dimensions (L x W x H)
Net/Gross weight
DC plug
Cable length
Supply voltage
Output power
Output voltage
Maximum output current
for t
AMB
Maximum output current
for t
AMB
Short circuit protection SCP /
overload protection OLP
Operation status indication
Operation conditions
* - output current of the power supply unit depending on ambient temperature. For temperature above 30°C
maximum output current is limited according to graph 1. The power supply operation life time is limited by
reliability of the electrolyte capacitors which strongly depends of an operation temperature. Avoid excessive
temperature rise of the power supply!
Graph 1 Relation between output current and ambient temperature.
59 x 39 x 65 mm
<30°C
=40°C
Yes - LED diode
Switch mode power supply adapters
PSA12005, PSA12010, PSA12015
Edition: 1st from 09.07.2010
Supercedes edition:_ _ _ _ _
PSA12005
70 x 29 x 76 mm
70g/80g
DC5,5/2,1 female
110 V÷ 240 V AC 50/60 Hz
6W
MAX
500mA*
350mA*
Yes
o o
0 C ÷ 40 C , RH 10 ÷ 90 %, no condensation
1
PSA12010
71 x 46 x 68 mm
80g/95g
145 cm
12W
MAX
12 V DC
1000mA*
700mA*
Yes
No Yes - LED diode
EN
PSA12015
100g/120g
18W
MAX
1500mA*
1000mA*
Yes
