1. Charging the Smart Controller

It takes roughly 2 hours and 15 minutes to fully charge the Smart
Controller using the standard USB charger.
Power Outlet
(100 - 240 V)
Please use the official USB charger to charge the Smart Controller. When a standard USB charger is not
available, it is recommended to use an FCC / CE certified USB charger rated 12 V / 2 A.
• Please recharge the battery at least every three months to prevent over discharging - the battery will deplete
when stored for an extended period.

2. Mounting the WB37 Intelligent Battery

Press and hold the battery release
1
button.
Insert the Intelligent Battery into the
2
battery compartment. Make sure the
bottom of the battery is aligned to the
marking line in the compartment.
Push the battery to the bottom.
3
To remove the Intelligent Battery, press and hold the battery release button, then push the battery
upward.
Refer to the BS60 Intelligent Battery Station User Guide for Intelligent Battery charging details.

3. Mounting the 4G Dongle and SIM Card

Only use a DJI-approved dongle.
The dongle and SIM card enable the Smart Controller to access 4G network. Make sure to
deploy these correctly, otherwise, network access will not be available.
The dongle and SIM card are excluded.
USB-C Cable
USB charger
Remove the dongle compartment cover.
Insert the dongle into the USB port with the SIM card inserted
into the dongle.
Reattach the cover firmly.
2
1
3
5
