CSA MODEL FM150
184841
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
DUST COLLECTOR
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 3401
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Related Manuals for Wen 3401
Summary of Contents for Wen 3401
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe, reliable service.
-
Page 2: Table Of Contents
Collection Bag Capacity: 12 Gallons Collection Bag Filtration Rating: 35 Microns Assembled Dimensions: 34.25 x 13 x 14.2 in. Product Net Weight: 18.5 pounds Compatible with the WEN 28200 10 Ft. Dust Hose and the WEN 28221 20 Ft. Dust Hose... -
Page 3: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood. -
Page 4: Specific Rules For Dust Collectors
GENERAL SAFETY RULES POWER TOOL USE AND CARE 1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to a power source or carrying the tool. 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation. -
Page 5: Electrical Information
ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. -
Page 6: Unpacking
UNPACKING Carefully unpack and remove all contents from the box. Check all components and compare against the graph below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. PACKING LIST 1. -
Page 7: Assembly
ASSEMBLY WARNING: Do not attempt to plug in or operate your tool until the entire operator’s manual has been read and understood. Failure to do so could result in personal injury and damage to the tool. CASTER ASSEMBLY Your dust collector comes installed on a roller base. In- stall the casters onto the roller base to be able to move your dust collector around. -
Page 8: Operation
1. Connect the dust collector to your woodworking machine using a 4-inch dust collection hose. NOTE: Your dust collector is compatible with the WEN 28200 10 ft. dust hose and the WEN 28221 20 ft. dust hose, available at wenproducts.com. Adaptors may be needed depending the dust port size of your woodworking machine. - Page 9 LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
-
Page 10: Exploded View & Parts List
EXPLODED VIEW AND PARTS LIST... - Page 11 EXPLODED VIEW AND PARTS LIST Part No. Description Qty. 3401-001 Roller Base & Handle 3401-002 End Cap 3401-003 Caster With Braking 3401-006 Washer 3401-007 Cap Nut 3401-008 Handle Cover 3401-010 Hex Nut 3401-011 Mounting Bracket 3401-013 Hex Head Bolt 3401-014...
