Installation Instructions for
Wynfield Outdoor Post
G
ENERAL RODUCT NFORMATION
P
This product is safety listed for wet locations.
Incandescent version may be dimmed with a standard incandescent
dimmer.
LED
version may be dimmed with a
lamp manufacturer for additional information.
This instruction shows a typical installation.
POST
I
:
LED
dimmer. Consult
SAVE THESE INSTRUCTIONS!
CAUTION RISK OF FIRE
This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and
operation of the product and the hazards involved.
Use minimum 90°c supply conductors.
7400 Linder Ave, Skokie,
800.969.3347
www.generationlighting.com
© 2020 Generation Lighting.All rights reserved.
The "Generation Lighting" graphic is a registered trademark of
Generation Lighting. Generation Lighting reserves the right to
change specifications for product improvements without notification.
990
OP
8_202-WYN
82202, 89202
-
IL
160077
1.0
Advertisement
Related Manuals for Generation Lighting Wynfield Outdoor Post
Summary of Contents for Generation Lighting Wynfield Outdoor Post
- Page 1 © 2020 Generation Lighting.All rights reserved. This instruction shows a typical installation. The "Generation Lighting" graphic is a registered trademark of Generation Lighting. Generation Lighting reserves the right to change specifications for product improvements without notification. SAVE THESE INSTRUCTIONS!
- Page 2 Install the Fixture CAP NUT WASHER STUD COVER LAMP POST SCREW POST Connect the fixture to a suitable ground in accordance to local electrical codes. Connect the white fixture wire (square and/or rigid) to the neutral power line wire with a wire nut. Connect the black fixture wire (round and/or smooth) to the hot power line wire with a wire nut.
