Generation Lighting Perrywood Outdoor Wall Installation Instructions

Installation Instructions for

Perrywood Outdoor Wall

OUTDOOR

ENERAL RODUCT NFORMATION

These fixtures are intended to be installed utilizing

junction boxes.

This product is safety listed for wet locations.

Incandescent version may be dimmed with a standard incandescent

dimmer.

LED

version may be dimmed with a

lamp manufacturer for additional information.

This instruction shows a typical installation.

NEC

compliant

LED

dimmer. Consult

SAVE THESE INSTRUCTIONS!

8414201, 8514201, 8614203, 8714203

CAUTION RISK OF FIRE

This product must be installed in accordance with the applicable

installation code by a person familiar with the construction and

operation of the product and the hazards involved.

Use minimum 90°c supply conductors.

7400 Linder Ave, Skokie,

800.969.3347

www.generationlighting.com

The "Generation Lighting" graphic is a registered trademark of

Generation Lighting. Generation Lighting reserves the right to

change specifications for product improvements without notification.

990W8_1420_-PWD

160077

1.0
