Page 2: Specifications
1. Specifications Power Supply: AC100-240V,50-60Hz Power Consumption: 60W LED Source: 2*10W 4IN1 (RGBW) CREE LEDs Beam Angle: 25° Dimmer: 0~100% Linear Dimming Control mode: DMX 512,Master-slave,Auto run,Sound-activated DMX Channel: 9/17CH Rotation Angle: X 540 degree / Y unlimited rotation Dimming: 0%-100% linear dimming Connector: DMX via 3-pin XLR cable Date In and out: 3-pin XLR cathode and anode plug 1.Infinite rotation... -
Page 3: General Guidelines
1. Be very careful during installation. Since you will be working with a dangerous voltage you can suffer a life-threatening electric shock when touching live wired. 2. Never look directly into the light source, as sensitive persons may suffer an shock. - Page 4 Operating Instructions: Press button A “Menu” to choose different functions ， Press button “B” or “C” to amend parameter values, Press button “D” to“Enter” LCD display different functions: （Press button“Enter” to enter） Display Function ADDR A001-A512 address settings CHND 9CH, 17CH channel selection SLND MAST, SLAVE selection Select SOUD, AUTO(SP0—...
- Page 5 Mode 1: 9 Channels Functions Illustration 0-255 X motor operation 0-255 Y motor operation Dimming 0-255 1-100% Red Dimming 0—255 0-----100% Green Dimming 0—255 0-----100% Blue Dimming 0—255 0-----100% White Dimming 0—255 0-----100% Strobe 0-15 open light, 16-131 strobe from slow to fast , 132-139 open light, 140-181 fast off, slowly open, 182-189 open light, 190-231 slow off, quick...
- Page 6 Mode 2:17 Channels Data Illustration 0-255 level motor travel,0°-------540° 0-255 The level of motor tuning 0-255 Vertical Motor: 0-127, 360-degree stroke positioning; 128-191, forward rotation from fast to slow; 192 --- 255 reverse rotation from slow to fast. 0-255 Vertical Motor trimming: 0 ---- 255 (CH3 value is valid when 0 --- 127) Marco...
- Page 7 190-231 slow off quick opening, 232-239 opening, 240-247 random strobe, 248-255 opening Red Dimming 1 0—255 0-----100% Green Dimming 1 0—255 0-----100% Blue Dimming 1 0—255 0-----100% White Dimming 1 0—255 0-----100% Red Dimming 2 0—255 0-----100% Green Dimming 2 0—255 0-----100% Blue Dimming 2...
