AJAX DoorProtect Solar Plus Manual

Solar Plus Ajax
1. FEATURES
Wireless sensor Ajax DoorProtect is designated for doors and windows opening detection.
It functions as a part of Ajax security system.
2. SPECIFICATIONS
SPECIFICATION
Sensor type
Assembling type
Operating level
Uses
Socket to plug in the wire sensors
Tamper protection button
Radio signal power
Radio-frequency range
Maximum distance between sensor
and central unit
Power supply
Power supply voltage
Battery life
Operation temperatures range
Operation humidity
Dimensions
3. COMPONENTS
DoorProtect opening detection sensor, magnet, external contact, battery CR123A,
installation set, manual
4. SETTING-UP PROCEDURES
4.1 Before installing the sensor, it is required to register it with the Ajax security system. In
order to register the sensor, it is necessary to switch the Ajax security system's receiver to
«Add Device» mode (the receiver's manual explains how to accomplish it) and to put the
switch «2» (PICTURE 3) on the sensor to the «ON» position. Sensor's light must blink at the
moment of switching on. The registration request is transmitted at the moment the sensor
is switched on only! In case the registration was not successful, switch off the sensor, wait
for 5 seconds and switch it on again. If the sensor's light blinks constantly (each second
during one minute), it means that the sensor is not registered. The light blinks in the same
way if the sensor is deleted from the registration list. Non-registered sensor blinks also
throughout 3 seconds during each activation.
4.2 Having registered the sensor successfully, select an appropriate location to install it.
MEANING
wireless
removable
1 cm (0.4 in) (small magnet), 2 cm (0.8 in)
(big magnet)
indoors
available
available
20 mW
868 MHz (Europe); 915 MHz (USA)
2000 m (6562 ft) (open area)
CR123A battery
3V
Up to 7 years
from 0°С (+32°F) to +50°С (+122°F)
up to 80%
Ø20х90 mm (0.78x3.54 in)
Solar Security
DoorProtect
