ERB25 Rechargeable Battery Motor Instruction
Technical data
Motor Load Torque: 0.7Nm/34rpm 1.1Nm/28rpm
Battery Specification: Li-ion Batter, 2000mAH, 7.4V.
Notify:
●The side of motor head with SETTING button
should face to you ( toward outside)
● Motor antenna should be as straight as
possible in the position far away from metal objects. Directly contact
metal objects is prohibited; otherwise, the receivindistance will be influenced seriously.
●Please charge the battery when the motor alarm or work faltering
Operation
Item
Item
● Please skip the step and go to next If manufacturer has programmed a transmitter with motor
before delivery
Keep pressing the
Program the
SETTING button battery
1
first
pack for more than 3
transmitter
seconds
with motor
Press the CONFIRM
2
button on transmitter
1
Press UP button
Change
Press and hold LIMIT button
motor rotate
2
then press STOP button
direction
3
Press UP button
The whole limit setting must be finished at one times
Keep pressing LIMIT
1
button on any
programmed transmitter
Press DOWN button on
2
transmitter
Press STOP button When
Setup
3
motor running close to the
bottom limit
end-point of bottom limit
Press either UP or DOWN
4
button
Press CONFIRM button
5
on transmitter
Operation
Rlease this button when
motor jogs
Motor jogs, the program
has been done.
If motor goes up, please do
nothing, If motor goes down,
please do next step
Release both buttons when
motor jogs
Motor goes up, the motor
rotation direction has been
revised
Rleasethis button when
motor jogs
Motor runs down
Motor stops
Motor runs step by step to
adjust bottom limit
accurately
Motor jogs, down way
setting has been done.
Result
Illustration
