Summary of Contents for Aerotech AUTOMATION1-HyperWire
-
Page 1: Automation1-Hyperwire Card Hardware Manual
AUTOMATION1-HyperWire Card HARDWARE MANUAL Revision: 1.00.00... - Page 2 This manual contains proprietary information and may not be reproduced, disclosed, or used in whole or in part without the express written permission of Aerotech, Inc. Product names mentioned herein are used for identification purposes only and may be trademarks of their respective companies.
-
Page 3: Table Of Contents
HyperWire Card Hardware Manual Table of Contents Table of Contents AUTOMATION1-HyperWire Card HARDWARE MANUAL Table of Contents EU Declaration of Conformity Chapter 1: HyperWire™ Card 1.1. Installation 1.2. HyperWire Card Firmware 1.3. Cables 1.4. Environmental Specifications Appendix A: Warranty and Field Service... - Page 4 Table of Contents HyperWire Card Hardware Manual This page intentionally left blank. www.aerotech.com...
-
Page 5: Eu Declaration Of Conformity
HyperWire Card Hardware Manual EU Declaration of Conformity EU Declaration of Conformity Manufacturer Aerotech, Inc. Address 101 Zeta Drive Pittsburgh, PA 15238-2811 Product HyperWire Card Model/Types This is to certify that the aforementioned product is in accordance with the applicable requirements of the... - Page 6 EU Declaration of Conformity HyperWire Card Hardware Manual This page intentionally left blank. www.aerotech.com...
-
Page 7: Chapter 1: Hyperwire™ Card
If you want to operate without a HyperWire card, refer to the Operation without a FireWire or HyperWire Card section of FireWire or HyperWire Card Options in the Helpfile. To install a HyperWire card, use the procedure in Installation. www.aerotech.com... - Page 8 HyperWire Card Hardware Manual NOTE: All specifications and illustrations are for reference only and were complete and accurate as of the release of this manual. To find the newest information about this product, refer to www.aerotech.com. Figure 1-1: HyperWire Card Dimensions...
-
Page 9: Installation
2. To get access to the motherboard, remove the computer system cover. 3. Find an available PCIe slot, x4 or larger. If necessary, refer to your computer manual for information about available slots. Figure 1-2: Open PCIE Slot 4. Remove the cover of the available slot that you want to use. www.aerotech.com... - Page 10 6. Attach the metal tab on the card to your computer with the method in your computer manual. This is typically a mounting screw. 7. Put the cover on the computer. 8. Connect the computer to the power supply and power on the computer. www.aerotech.com...
-
Page 11: Hyperwire Card Firmware
1-4) to determine if the HyperWire card is initialized. The LED should come on and remain illuminated immediately after you turn on the PC. The LED can also flash briefly during a PC restart. If the LED continues to flash or remains off, the default firmware image could be corrupt. Figure 1-4: Default Position of JP1 www.aerotech.com... - Page 12 11. Reconnect the HyperWire cable and determine whether there is HyperWire communication between the PC and the drive. A HyperWire card configured in Recovery [2-3] mode might not establish HyperWire communication between the PC and the drive. If there is no communication, make certain the JP1 is set to [1-2] www.aerotech.com...
-
Page 13: Cables
10 N/mm (minimum) [FOTP-41] Impact Resistance 0.5 N·m (minimum) [FOTP-25] Flexing 300 cycles [FOTP-104] Twist Bend Exceeds FOTP-85 Fiber Optic Cable Twist Test Short Term 25 mm (minimum) Bend Radius Long Term 30 mm (minimum) Durability 100 Cycle Minutes (minimum) www.aerotech.com... -
Page 14: Environmental Specifications
31°C and decreases linearly to 50% relative humidity at 40°C. 0 m to 2,000 m above sea level. Operating Altitude If you must operate this product above 2,000 m or below sea level, contact Aerotech, Inc. Pollution Degree 2 Pollution Typically only nonconductive pollution occurs. -
Page 15: Appendix A: Warranty And Field Service
Aerotech makes no warranty that its products are fit for the use or purpose to which they may be put by the buyer, whether or not such use or purpose has been disclosed to Aerotech in specifications or drawings previously or subsequently provided, or whether or not Aerotech’s... - Page 16 Aerotech's approval. On-site Warranty Repair If an Aerotech product cannot be made functional by telephone assistance or by sending and having the customer install replacement parts, and cannot be returned to the Aerotech service center for repair, and if Aerotech determines the problem could be warranty-related, then the following policy applies:...
-
Page 17: Appendix B: Revision History
HyperWire Card Hardware Manual Appendix B: Revision History Appendix B: Revision History Revision Description 1.00.00 New Manual www.aerotech.com... - Page 18 Appendix B: Revision History HyperWire Card Hardware Manual This page intentionally left blank. www.aerotech.com...
-
Page 19: Index
Declaration of Conformity Default Jumper (JP1) Position Support Default Position of JP1 Dimensions Table of Contents Cable Technical Support HyperWire Card FOTP-104 FOTP-25 Warranty and Field Service FOTP-41 FOTP-85 Global Technical Support Humidity HyperWire Cable Part Numbers HyperWire Card Dimensions www.aerotech.com Index... - Page 20 Index HyperWire Card Hardware Manual This page intentionally left blank. Index www.aerotech.com...
