- Page 1 MODEL F20 SVE Water Treatment Equipment Control Valve Installation and Service Manual...
- Page 2 MODEL F20 SVE Installation Sheet............1 Programming............2 Valve Installation............9 Equipment Installation...........11 Dimensional Drawing..........12 Assembly Drawings and Part Numbers......13...
- Page 3 MODEL F20 SVE Equipment Supplier: Address: _________________________________________________________________ Phone: ___________________________ Equipment Model: _____________________ Installation Date: ___________________ Installer's Name: ______________________ _____________________________________________________________________________ Total Hardness: ____________grains/gallon, ______________________ mg/l (grams/m Turbidity: ___________________NTU, pH: ______________TDS: ________________ Chlorine: ______ ppm (mg/l), Nitrates: _______ ppm (mg/l), Arsenic: _______ ppm(mg/l)
- Page 4 MODEL F20 SVE Pre-Programming: Understanding the Displays Service Indicator: Dot on = valve in service blinking dot = will Flow Indicator have an extra regeration cycle P.M. Indicator Dot on = In progamming mode Regeneration button/enter Up and Down arrows...
- Page 5 MODEL F20 SVE Displays: Other Displays: PAGE 3...
- Page 6 MODEL F20 SVE Flow Display: * TPH=m /hour Preparing to program PAGE 4...
- Page 7 MODEL F20 SVE PAGE 5...
- Page 8 MODEL F20 SVE （Calculate & Change） & salt dosage PAGE 6...
- Page 9 MODEL F20 SVE （Calculate & Change） & salt dosage (Note: For other meters change value to their K factor Our bypass meter, K = 72 pulses/gal or 19 pulses/liter) PAGE 7...
- Page 10 MODEL F20 SVE 3 - 10 ( Note : For other meters change value to their K factor Our bypass meter,K = 72 pulses/gal or 19 pulses/liter )
- Page 11 MODEL F20 SVE General Information Location: Servicing: Hydraulics: Plumbing: Electrical: and must satisfy the demand. Operating Parameters: Chemical: Installation PAGE 9...
- Page 12 MODEL F20 SVE Riser o-ring PAGE 10...
- Page 13 MODEL F20 SVE tightening could damage threading. PAGE 11...
- Page 14 MODEL F20 SVE INLET OUTLET 51.68 (2") 108.52 (4.3") 86.99 (3.4") 192.2 (7.6") 2.5" 8NPSM OD=1.05" Unit: mm (Inch) PAGE 12...
- Page 15 MODEL F20 SVE PAGE 13...
- Page 16 MODEL F20 SVE NOTE: PAGE 14...
- Page 17 MODEL F20 SVE PAGE 15...
- Page 18 MODEL F20 SVE Item No. Quantity Part No. Description 051-00378-00 Valve Body 060-00020-00 Seal 051-00017-00 Spacer 052-00177-00 Piston 051-00011-00 Retainer, Piston Rod 051-00041-00 Quad Ring Cover-EPA 060-00011-00 Quad Ring-EPA 051-00040-00 End Plug 052-00178-00 Piston Rod 068-00004-00 Spring Pin-PRA 052-00032-00 Plate...
- Page 19 MODEL F20 SVE V A LV E 047-00000-00 Meter Cable Assembly 051-00034-00 Meter turbine housing 052-00029-00 Adapter Clip 066-00045-00 Screw,tcp,No.8-18x9/16,b,JIS SUS304 060-00004-00 O-ring, As-119 051-00037-00 Cover Bearing 060-00015-00 O-ring, As-028 051-00035-00 Bearing 051-00052-00 Flow Straightener F ” r e l...
- Page 20 MODEL F20 SVE 10 9 8...
- Page 21 MODEL F20 SVE e t I y t i p i r 051-00467-00 Plug Outlet 099-02392-00 Flow Valve Assembly 051-00472-00 Retainer 051-00480-00 Elbow Connector 051-00479-00 Straight Connector 060-00004-00 O-ring AS119 060-00130-00 Block 066-00002-00 Screw 4-20x1/2 069-01148-00 Label-Inlet 051-00470-00 Knob 051-00468-00...
- Page 22 MODEL F20 SVE Relay CB1-F20SVE Circuit Board VDM-Valve Drive Motor EM-Electronic Flow Meter (Optional) SW1-Homing Switch SW2-Step Switch SW3 – Auxiliary Switch HCAM-Homing Cam DFSCAM-Downflow Step Cam PAGE 20...
- Page 23 MODEL F20 SVE A. TO REPLACE INJECTORS SCREEN AND BRINE VALVE pushing the regeneration button checking for proper functioning in all cycles. Make sure to go back to the Turn off water supply to conditioner: service position. On three valves bypass system: First open bypass Make sure there is enough salt in brine tank.
- Page 24 MODEL F20 SVE TO REPLACE TIMER Make sure comic tip is facing outward. After lubricating the new meter o-rings with silicone, Follow steps from B.1 to B.3. assemble meter to valve ports making sure that meter Follow steps from B.9 to B.11.
- Page 25 MODEL F20 SVE Read This First SYMPTOM PROBABLE CAUSE SOLUTION 1. Softener fails to regenerate A. Power supply (LED off): Lack A. Plug unit to constant power source. automatically. Make sure the transformer delivers of power to unit or damaged PC board.
- Page 26 MODEL F20 SVE SYMPTOM PROBABLE CAUSE SOLUTION 3. Poor water quality. A. External short circuiting: Bypass valve A. Make sure bypass valve is closed. not completely closed. B. Check items listed above in #2: Low B. See solutions listed in #2 flows or damaged resin.
- Page 27 MODEL F20 SVE SYMPTOM PROBABLE CAUSE SOLUTION 8. Control valve cycles A. Faulty home switch. A. Check for loose or damaged home and continuously. cycle switches. Replace or align them correctly. See error message on page 28. 9. Continuous flow to drain A.
- Page 28 MODEL F20 SVE Error Codes Note HCAM = Home Cam SCAM = Cycle Cam Going into regeneration, display shows 1 ---, 1) Motor may be burned. Err 0 but motor does not move. After 10 minutes, 2) Wire nuts to motor may be loose.
- Page 29 MODEL F20 SVE " ” 2 l a i l l a 100-00148-00 BWFC Assembly 7.0 GPM REFILL FLOW CONTROLS ASSEMBLY 100-00164-00 RFC Assembly (0.125GPM) BACK WASH FLOW CONTROLS (BWFC washers) 100-00165-00 100-00165-00 RFC Assembly (0.25GPM) RFC Assembly (0.25GPM) 060-00079-00 060-00079-00 1.0 GPM...
- Page 30 MODEL F20 SVE OPTIONS VALVE MATERIAL Nory1 Injector Model numbers: PORTS 015, 025, 050, 075, 100, 200 and 400 to use from 0.15 ft³ to 4.0 ft³ of resin Noryl Material Backwash Flow Controllers: Base 2.5'' 1/2'' housing for 1.0, 1.3, 1.7, 2.2, 2.7, 3.0, 4.0, 5.0 and 7.0 Riser,OD 1.05''...
