domat FC013 Protocol Manual

FC013 – EC (0...10 V) fan controller (with UC013), RTC, 2xDO, 3xAO 0-
10 V, 2xDI, 2xRS485
- 50 words can be read at the same time (i.e. 100 bytes)
- whole range can be addressed bitwise
- the whole memory is mirrored as read-only from address 0x101 (e.g. 257 dec)
name register
module ID 1 LSB
1 MSB
firmware 2 LSB
2 MSB
status LSB 3 LSB
status MSB 3 MSB
address 4 LSB
FC013 Fancoil controller
MODBUS
Release 18.12.2014 ver. 01900
type description
R module type identification
R firmware version
R, W RAM module status lower byte
bit 0 – write to EEPROM enabled
bit 1 – SW reset enabled
bit 4 – init EEPROM
R, RAM module status upper byte
bit 0
bit 1
bit 2 – 1 – EEPROM initialized
bit 3 – N/A
bit 4 – 0
bit 5 – SW reset enabled
bit 6 – 0
bit 7 – commissioning mode (1 –
R,W Modbus module address
EEPROM (default = 1)
(0x01) To distribute load, fans and
outputs are enabled after address
modulo 10 secs
0 normal mode
1 init mode
1 at the next EEPROM
write attempt will all data
be written to EEPROM,
0 at the next EEPROM
write attempt will received
data be written to RAM
only
indication
active)
notes / defaults
0505
hex
13
hex
Init EEPROM follows if
the INIT switch was ON at
power up, and if INIT
switch was OFF at setting
bit 4 to 1 (indicated by bit
2 in Status MSB)
SW reset follows if
enabled and 1 is written
into the SW reset register
(address 1002)
!!! the change will be
effective after restart only
(however the register will
be set immediately)
