- Page 5 SKI650 Series Notes for Safe Operation ■ Before Installation WARNING Do not install or operate the controller that is damaged or has missing parts. Otherwise, it may result in equipment damage or harm life. ■ Installation CAUTION ◎ Hold the bottom of the controller when installing or moving the...
- Page 6 SKI650 Series ■ Operation CAUTION ◎ Do not open or remove the front cover when operation. Otherwise it may cause an electrical shock. ◎ ; can not make the pump dry-runfor a long time. Before testing the pump must be installed In order to test the pump, the maximum dry-runtime is not more than 15s ◎...
- Page 7 SKI650 Series Chapter 1 How It Works The SKI650 solar pumping system serves to provide water in remote applications where electrical grid power is either unreliable or unavailable. The controller can convert DC from the PV array to AC， and drive kinds of pumps. In sunny days, the SKI650 solar pumping system can continuously pump water.
- Page 18 SKI650 Series 2.5 Outline &Installation Dimensions Outline &installation dimensions diagram 2.5.1 Outline &installation dimensions diagram Figure 2 - 17 -...
- Page 20 SKI650 Series Chapter 3 Mechanical and Electrical Installation 3.1 Mechanical Installation 3.1.1 Overheat protection Install the SKI650 solar pump inverter in a control box with control terminals and power wiring. Install the control box out of direct sunlight to prevent overheating and reduced performance.
- Page 21 SKI650 Series The SKI650 solar pump inverter must be installed into a control box which has a tight enclosure to avoid direct sunshine, rain, dust, moisture, animals, plants, etc. The control box should have a bottom gland plate for installing wire cord or conduit.
- Page 23 SKI650 Series WARNING Before connect DC wiring, following the steps below to prevent hazardous electric shock resulting in serious injury or device burning. • Make sure that the external DC disconnect switch is off. •To ensure that the polarity of the solar array cable must be properly connected to the controller's R, T pole, otherwise possible damage the controller.
- Page 27 SKI650 Series Chapter 4 Start-up and Operation 4.1 Keypad Description 50. 00 Indicator Light Digital Display Alarm Shift Key SHIFT JOG Key Up Increase Key ENTER Program/Exit Key Data Enter Key STOP S top/Fault Reset Key Run Key RESET Down Decrease Key...
- Page 28 SKI650 Series Use it to select displayed parameters cyclically during running or stop status. In parameter setting shift key mode, press this key to select the bit to be modified. Start to run the controller in keypad control run key mode.
