CG100SK
AC S
OCKET
U
M
SER
ANUAL
CG100SK
AC Socket – UK Standard
V
1.1
ERSION
21 F
, 2020
EBRUARY
Disclaimers and Copyright
Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the
manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as
insuring anyone against liability for infringement of letters patent.
Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however,
CityGrow Energy Systems Limited makes no representation, warranty, or guarantee in connection with this publication
and hereby expressly disclaims any liability or responsibility for loss or damage resulting from its use or from the use
of any product or methodology described herein; for any violation of any federal, state, or municipal regulation with
which this publication may conflict; or for the infringement of any patent from the use of this publication. Nothing
contained in this publication should be viewed as an endorsement by CityGrow Energy Systems Limited of any particular
manufacturer's products.
i

Advertisement

loading
Need help?

Need help?

Do you have a question about the CG100SK and is the answer not in the manual?

Questions and answers

Summary of Contents for CityGrow CG100SK

  • Page 1 Nothing contained in this publication should be viewed as an endorsement by CityGrow Energy Systems Limited of any particular manufacturer’s products.
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 3: Table Of Contents

    Table of content Introduction ....................1 Understanding the product ................2 Installation ....................3 Operation instruction .................. 5 Pairing CG100SK with CityGrow’s remote products ......... 6 Specification ....................8...
  • Page 4: Introduction

    1. Introduction Thank you for choosing CityGrow’s product. CG100SK AC Socket is highly-functional, user-friendly and installation-friendly. It is specially designed for CityGrow home automation system. Description ZigBee wireless remote control. Based on IEEE 802.15.4. 2.4GHz radio frequency. Embedded type AC socket.
  • Page 5: Understanding The Product

    2. Understanding the product...
  • Page 6: Installation

    WARNING! Install in accordance to all national and local electrical codes. IMPORTANT! CityGrow® is not liable for any damage incurred with the misuse of the product. IMPORTANT! Pre-setup can only be done by a professional technician or manufacturer agent.
  • Page 7 STEP 3: Connect the main power cable to the Live and Neutral terminals at the rear cabinet of the device. STEP 4: Fasten the screws of all terminals and check that the wires are properly secured. Install the AC power socket on the wall by fastening the two screws. STEP 5: Press the ON/OFF Button to test if the wiring is connected correctly.
  • Page 8: Operation Instruction

    4. Operation instruction COVER PLATE 1. Door (Slide to Open) 2. ON/OFF Button 3. LED Indicator OPEN MAIN UNIT 4. Connector 5. Screw Holes CONN. 6. Fuse 7. Reset Button RESET Press ON/OFF Button once to toggle between ON and OFF. LED ON indicates the Socket is OFF.
  • Page 9: Pairing Cg100Sk With Citygrow's Remote Products

    5. Pairing CG100SK with CityGrow’s remote products STEP 1 CONN. Connect one end of the provided USB Cable to the RESET CG100SK and the other end to a PC. STEP 2 The CG100SK must be programmed with an ID. Refer to the User Manual for the instructions of the “HomeNET Planner 2”...
  • Page 10 STEP 5 CONN. Press and release the desired ON/OFF Button once to RESET confirm the pairing. STEP 6 CONN. The pairing process is complete. RESET NOTE: The CG100SK can be paired with up to 8 pieces of CityGrow control plate products.
  • Page 11: Specification

    6. Specification Item Specification Input voltage AC220V-240V, 50Hz (UK) Loading 13A (UK) Functions Remote control ON/OFF Range 60M (line of sight), ZigBee Mesh Network Operating temperature 0°C to 40°C Operating humidity 20% to 95% non-condensing Unit Dimension L x W x D 115 x 87 x 46mm (mm) Storage...
