CG500MS
ZIGBEE PIR MOTION SENSOR
U
M
SER
ANUAL
CG500MS
ZigBee PIR Motion Sensor
V
1.1
ERSION
17 J
, 2014
ANUARY
Disclaimers and Copyright
Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the
manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as
insuring anyone against liability for infringement of letters patent.
Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however,
Citygrow Energy Systems Limited. makes no representation, warranty, or guarantee in connection with this
publication and hereby expressly disclaims any liability or responsibility for loss or damage resulting from its use or
from the use of any product or methodology described herein; for any violation of any federal, state, or municipal
regulation with which this publication may conflict; or for the infringement of any patent from the use of this
publication. Nothing contained in this publication should be viewed as an endorsement by Citygrow Energy Systems
Limited. of any particular manufacturer's products.
i
Advertisement
Table of Contents
Related Manuals for CityGrow CG500MS
Summary of Contents for CityGrow CG500MS
- Page 1 Nothing contained in this publication should be viewed as an endorsement by Citygrow Energy Systems Limited. of any particular manufacturer’s products.
-
Page 2: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
Table of content Introduction ....................1 Understanding of the product ............... 2 Dimensions ....................3 Installation ....................4 Application notes ..................7 5.1. Connect the PIR with external power supply ........7 5.2. Dry contact output and intelligent PIR sensing........9 5.3. -
Page 4: Introduction
1. Introduction Thank you for buying Citygrow’s product. CG500MS ZigBee PIR Motion Sensor is designed for easy installation. The application can be home automation, energy saving and security purpose. Description 1. ZigBee wireless remote control. 2. Based on IEEE 802.15.4. -
Page 5: Understanding Of The Product
2. Understanding of the product LED indicator Screw Front cover Program port PIR Sensor Head Tamper switch LED jumper External power / Dry contact output connector Main unit Wall mount hanger Door Battery compartment is for storage of cable connectors Reset of CG101AD external power Function... -
Page 6: Dimensions
3. Dimensions Main unit 100mm 53mm 43mm Wall mount hanger 62mm 62mm 31mm 32mm... -
Page 7: Installation
Step 2: Open the front cover. Step 3: Connect the CG101UT5, CG101UTC cable from the program port to a PC that installed with Citygrow’s HomeNET Planner Software. Website to download: www.citygrowsys.com Please note that you DO NOT need to insert the batteries or connect the product with external power. - Page 8 Step 6: Connect the CG101AD external power supply to the CG500MS. The LED indicator will be ON for 2 seconds, if a motion is detected, the LED indicator will be ON for 2 seconds again.
- Page 9 Step 7.2: Mount the wall mount hanger on the wall Step 7.3: Insert the PIR sensor into the wall mount hanger. 2.2M typical installation...
-
Page 10: Application Notes
Step 8: Try a walk test and see the LED indicator is operating correctly or not. If a motion is detected, the LED with be ON again for 2 seconds. If everything is correct, remove the front cover again and remove the LED jumper. (see section 2). - Page 11 5.1b. Plug the provided external DC power connector into the external DC socket and route the cable according to the following diagram. Then connect the DC output of the CG101AD to the external DC power connector, pay attention to the polarity of the wires, black is GND, red is DC 6V.
-
Page 12: Dry Contact Output And Intelligent Pir Sensing
Wire connectors 5.2. Dry contact output and intelligent PIR sensing. When PIR detects moving object, it will send the wireless signal to Citygrow’s home automation system to trigger a scene that may include lighting, curtain, AV equipment, A/C …. Etc. -
Page 13: Clear Memory
6. Clear Memory In order to perform the Clear Memory function, please follow the below steps: STEP 1 Reset Function Press and HOLD Function button STEP 2 CONTINUE holding onto the Function Button. Press and release the Reset Button once. STEP 3 Wait until the LED Indicator begins BLINKING. -
Page 14: Specification
7. Specification Item Specification Power requirement External DC6V input ( Powered by CG101AD AC input, DC output Mini power supply) ZigBee Wireless ZigBee wireless remote control. communication Based on IEEE 802.15.4. standard 2.4GHz radio frequency RF communication 100M ( open area) distance PIR detection Up to 5m radius at 25 deg C at 2.2m height...
