User Manual
SSM 6000 Classic
Date revised last: January 2006
Software Version 2.60
Version 800-01.06.EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSM 6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PRONOVA SSM 6000

Summary of Contents for PRONOVA SSM 6000

  • Page 1 User Manual SSM 6000 Classic Date revised last: January 2006 Software Version 2.60 Version 800-01.06.EN...
  • Page 3 SSM6000 biogas analyzer. Analyzer versions "A" and "B" are currently available. Analyzers with the new hardware are marked "SSM 6000 (B)" on the rating plate and on the calibration certificate. The "B" version differs from its predecessor version in terms of connector layout and with regard to the type of inputs and outputs, for example.

  • Page 5: Table Of Contents

    Requirements for the plant of installation, power supply Measuring input and output conditions, calibration gases Scope of delivery, rating plate and test certificates Dimension drawing of the SSM 6000 system Installing the gas analyzer 3.5.1 Unpacking and assembling the gas analyzer 3.5.2...
  • Page 6 Setting the measuring interval 6.2.4 Other settings Checking the interface functions Performing a test measurement Starting normal measuring operations CALIBRATION General information Calibration setup and calibration gases Recording the actual condition Calibration procedure Check measurement Resuming measuring operations 800-01.06.EN SSM 6000 User Manual...
  • Page 7 11.5 Accessory connection cables 11.5.1 PORT 1 connection cable 11.5.2 PORT 2 connection cable 11.6 Connection diagrams – Analyzer versions A / B The description of the PROFIBUS interface can be found at the end of this documentation. 800-01.06.EN SSM 6000 User Manual...

  • Page 9: General Safety Information

    Before performing any fault-finding or repair work, or before replacing any parts, disconnect the device from any voltage sources! In the event that work must be performed on the live, opened device, this may only be carried out by an informed expert who must be familiar with the related risks and hazards! 800-01.06.EN SSM 6000 User Manual...

  • Page 11: Introduction

    The analyzer features ease of operation and a clear-cut display structure. In terms of time and frequency of use, the SSM 6000 family can draw on the largest experience of all biogas analyzers available on the market.

  • Page 12: Importance Of The Measured Variables

    Gas mixtures with critical concentration relationships between methane and oxygen are flammable. Although critical gas mixtures of this kind are very rare in biogas plants, the utmost must be done in order to avoid the risk of ignition. In the SSM 6000, a detonation protection unit separates the analyzer from the biogas plant.

  • Page 13: Hardware Description

    SSM 6000 HARDWARE DESCRIPTION 2 HARDWARE DESCRIPTION Measuring characteristics The SSM 6000 analyzer was developed for the discontinuous measurement of CH S, O , CO und H in biogenic gases. The table below contains details concerning measuring ranges, etc. Gas type...

  • Page 14: Process Flow Chart And Measuring Process

    During steps 5 and 6, both gas paths of the analyzer are then once again flushed with ambient air and the values measured are displayed on the front panel at the end of the measuring process. 800-01.06.EN SSM 6000 User Manual...

  • Page 15: Display And Control Panel

    Navigation through the user menus is possible in setup mode via the membrane keypad (esc, up, down, enter). The setup mode is activated via the key-operated switch. Withdrawing the access key prevents manipulation by unauthorized persons. The analyzer is switched on and off via the "power" button. 800-01.06.EN SSM 6000 User Manual...

  • Page 16: Measuring-Gas Filter

    Measuring-gas filter Several filters are integrated into the gas path of the SSM 6000 in order to protect the sensors and other components of the system. The filters clean the biogas and the ambient air drawn in, thereby increasing both the service life of the sensors and the measuring precision of the system.

  • Page 17: Measuring Gas Cooler

    2.2.6 Housing rinsing The SSM 6000 additionally comes with a fan unit that discharges the heat of the measuring-gas cooler and rinses the housing with ambient air. The flow rate of the fan totals around 56 cubic meters per hour, so that the generation of a flammable gas mixture within the analyzer is safely prevented.

  • Page 18: Gas Connections / Safety Features

    The solenoid valves are controlled and the measuring points selected by the SSM 6000. A measuring process can be triggered manually via the digital inputs at port 1 or the (optional) Profibus interface.

  • Page 19: Automatic Shut-Off Unit (Option)

    Automatic shut-off unit (option) The SSM 6000 biogas analyzer is designed for pressures of –50 < p >5 hPa at the measuring-gas input. In the case of higher admission pressures which can, for example, occur with gas motors with supercharger, biogas flows through the measuring-gas cooler even during measuring pauses due to the elevated pressure level.

  • Page 20: Electrical Connections

    The mains disconnector switch must be marked in a manner that clearly shows the equipment to be disconnected. Signals and interfaces The SSM 6000 analyzer comes with the following connections for communicating with peripheral equipment. Plug connector Description Port 1 Analyzer version "A"...

  • Page 21: Hardware Installation

    ) or hydrogen chlorides (such as moist HCl), and chlorine-containing gases or aerosols must be cooled or pre-absorbed. Calibration gases for calibration For information concerning the calibration gases for calibrating the gas analyzer, please refer to the "Calibration" section. 800-01.06.EN SSM 6000 User Manual...

  • Page 22: Scope Of Delivery, Rating Plate And Test Certificates

    20 m PVC hose 4x1mm (plus an additional 10m per measuring point with the measuring-point switch option) Replacement fuse for SSM 6000 (miniature fuse, 1A slow-blow, 4x20mm) Data cable for RS232 interface (length: 3m) User manual (German or English) CD-ROM with operating manually (pdf format) with gsd file for Profibus connection...

  • Page 23: Dimension Drawing Of The Ssm 6000 System

    SSM 6000 HARDWARE INSTALLATION Dimension drawing of the SSM 6000 system Fig.: Connection dimensions of the SSM 6000 During installation, free space of at least 15 cm must be left on the right hand side of the analyzer and at least 25 cm underneath the analyzer.

  • Page 24: Installing The Gas Analyzer

    A distance of at least 15 cm should be maintained between the right hand side of the device and the nearest wall in order to ensure sufficient air circulation and to enable the replacement of the housing filter. 3.5.2 Electrical connections All electrical connections are located on the underside of the analyzer. Fig.: Analyzer view from below (standard) 800-01.06.EN SSM 6000 User Manual...
  • Page 25 Wire diameter, including insulation, up to 3mm / outside diameter 5.6 to 9 mm Connecting the voltage supply within the device by the customer is not permitted by the manufacturer and will render the guarantee invalid. 800-01.06.EN SSM 6000 User Manual...
  • Page 26 Insert the prepared cable into the contact support. Tighten the union nut. During tightening, QUICKON automatically establishes the contact and the strain relief function. Re-connecting the power cable Cut off wire ends approx. 20mm. Erneute Montage wie zuvor beschrieben. 800-01.06.EN SSM 6000 User Manual...
  • Page 27 The "open collector" transistor outputs of analyzer version "B" are short-circuit resistant and can be read and/or used to control the solenoid valves either by using the 12-V supply voltage of the analyzer or by an external voltage supply of 35VDC max. 800-01.06.EN SSM 6000 User Manual...
  • Page 28 CAN interface (option) The CAN interface for the output of measured data via a CAN bus system is not yet supported by the software in its current version. Connector module at the analyzer: D-sub 9-pole, plug connector 800-01.06.EN SSM 6000 User Manual...

  • Page 29: Connecting The Gas Pipes

    Cut hose at a right angle. Push knurled nut and clamping ring over the end of the hose. Push the end of the hose fully onto the sleeve. Screw on the knurled nut and tighten by hand. 800-01.06.EN SSM 6000 User Manual...
  • Page 30 The SSM 6000 biogas analyzer is designed for pressures of –50 < p >5 hPa at the measuring-gas input. In the case of higher admission pressures which can, for example, occur with gas motors with supercharger, biogas flows through the measuring-gas cooler even during measuring pauses due to the elevated pressure level.

  • Page 31: Using The Gas Analyzer

    S). The cursor flashes in front of the respective entry. Press <enter> in order to confirm the selection. The cursor moves to the first digit of the value that is currently adjusted (such as the numeral 1 of the value 1440). 800-01.06.EN SSM 6000 User Manual...

  • Page 32: Starting A Measurement

    Not every interval is permitted. The interval must be a divisor of 1440, i.e. the number of minutes of a day. If the value entered does not fulfill this requirement, the SSM 6000 automatically uses the nearest setting. With the setting selected above, H S is measured every 480 minutes and hence three times a day at 4:00 a.m., 12:00 noon, and 8:00 p.m, for...
  • Page 33 Further details concerning the PROFIBUS interface can be found in the appendix to this documentation. In the case of external control of the analyzer, the mode should be selected in order to avoid overlapping with the MANUAL measuring interval in automatic measuring mode. 800-01.06.EN SSM 6000 User Manual...

  • Page 34: Menu Structure

    _ 0-20 mA 7 4-20 mA SELECTED ENGLISH _ OPERATIONMODE _ GERMAN _ EVERY 0005 s _ ENGLISH ANALOG OUTPUT: ANALOG-OPERATEMODE: SELECTED 0-20 mA _WARM 0mA _MESS VAL _ 0-20 mA _SETUP 2mA _ 4-20 mA _STBY 800-01.06.EN SSM 6000 User Manual...

  • Page 35: Menu And Function Overview

    Not every interval is permitted. The interval must be a divisor of 1440, i.e. the number of minutes of a day. If the value entered does not fulfill this requirement, the SSM 6000 automatically uses the nearest setting. However, the measuring interval should not be set at a value of less than 120 minutes.
  • Page 36 PLEASE LEAVE SETUP Note: In the case of analyzer version "A", measuring-point switching takes place by equipment provided by the customer, so that it does not matter which measuring point is selected. 800-01.06.EN SSM 6000 User Manual...

  • Page 37: Calibration Parameters

    Only those gases that were activated in the GAS TYPES menu _ NO are considered. The settings in the CAL GAS CONCENTRATION menu are used as reference _ YES values. 800-01.06.EN SSM 6000 User Manual...

  • Page 38: Device Options

    / yellow when the gas concentration values are displayed. DATALOGGER: 3265 OUTPUT TO LCD: _ OUTPUT TO RS232 _ 15.01.01 12.00 _ OUTPUT TO LCD _ 16.01.01 00.00 _ RS232 INTERVALL _ 16.01.01 12.00 800-01.06.EN SSM 6000 User Manual...
  • Page 39 16.07.03 13:02;00,0;0001;20,8;00,0;23,8;1014;4; As a precondition for the transmission of data from the SSM 6000 to the PC, the terminal program must first be configured. This procedure is described here using the "HyperTerminal" program under MS Windows as an example. However, the properties of the serial interface can also be transferred to other terminal programs.
  • Page 40 In this dialog, you must now configure the interface. Edit the following parameters and subsequently click to confirm: Bits per second 38400 Data bits Parity none Stop bits Protocol / flow control none The HyperTerminal is now completely configured and is opened. 800-01.06.EN SSM 6000 User Manual...
  • Page 41 Transmitting measured data As a precondition for transmitting measured values from the SSM 6000, the analyzer must be connected via the RS232 interface to the serial interface (COM1 or COM2) of the PC.
  • Page 42 (Important! Select "All files (*.*) for the file type in order to have the txt file displayed.) MS Excel starts a text wizard which performs the import operation. Select the option and continue with "Separate" Continue > 800-01.06.EN SSM 6000 User Manual...
  • Page 43 Exit process. The measured values are imported to an Excel chart and can now be evaluated. The measured data can be presented in diagrams and used for other calculations. 800-01.06.EN SSM 6000 User Manual...

  • Page 44: Analog Measured-Value Outputs

    The following values can be set: 0 / 2 / 4 mA or VAL (analog value of the last measuring process) XmA (0 or 4mA, zero value of the edited output range 0-20 / 4-20mA) 800-01.06.EN SSM 6000 User Manual...

  • Page 45: Sensor Data

    S,/ 850 ppm H / 0 percent by volume of O / 40 percent by volume of CO In the case of analyzer version "B", the device temperature is additionally displayed in the first line. 800-01.06.EN SSM 6000 User Manual...

  • Page 46: Auto/Manual Mode

    Sensor signal H (instead of CO ) Zero gas Biogas / calibration gas 0750 - 0900 5.3.4 AUTO/MANUAL MODE The SSM 6000 features two different operating modes which can be selected under this menu AUTO/MANUAL MEAS.: SELECTED AUTOMAT item. _ MANUAL MEAS.

  • Page 47: Select Language

    DD:MM:YY format. _ DATE : 11:40:02 _ TIME : 07.11.04 Note that the clock of the SSM 6000 does not automatically switch to daylight saving time and winter time. Leap years are, however, considered. 800-01.06.EN SSM 6000 User Manual...

  • Page 48: Setting Into Operation

    Switching the gas analyzer on In order to set the SSM 6000 into operation, proceed as follows: Connect voltage supply. Press the power button on the front panel in order to switch the analyzer on.

  • Page 49: Setting The Measuring Interval

    Not every interval is permitted. The interval must be a divisor of 1440, i.e. the number of minutes of a day. If the value entered does not fulfill this requirement, the SSM 6000 automatically uses the nearest setting. With the setting selected above, H S is measured every 480 minutes = three times a day at 4:00 a.m., 12:00 noon, and 8:00 p.m.

  • Page 50: Performing A Test Measurement

    In the case of external control of the analyzer via the interfaces of the digital inputs, the mode should be selected in order to MANUAL avoid overlapping with the measuring interval in automatic measuring mode. 800-01.06.EN SSM 6000 User Manual...

  • Page 51: Calibration

    In order to ensure correct measuring results within the specified tolerances, analyzers and systems must be calibrated at regular intervals. With the SSM 6000, the individual gas types are calibrated using certified calibration gases and/or calibration gas mixtures. Note that incorrect calibration leads to incorrect results during subsequent measurements! Before any service or maintenance intervention, the higher-level system (plant control system) must be notified of any such work in advance in order to avoid emergency shut-down of the motor in response to incorrect measuring values.

  • Page 52: Recording The Actual Condition

    SSM 6000 CALIBRATION The process of calibrating the SSM 6000 consists of the following steps: Rinsing the gas ducts and pipes with ambient air in order to record the sensor zero points (steps 1 and 2) Determining the sensor sensitivity values using biogas / calibration gas (steps 3 and 4) Rinsing the system using filtered ambient air (steps 5 and 6).

  • Page 53: Calibration Procedure

    After the sensor sensitivities are taken over, both gas paths of the analyzer are once again rinsed with ambient air. Completion of the calibration process must be confirmed once again. The device returns to stand-by mode on operation of the key switch. 800-01.06.EN SSM 6000 User Manual...

  • Page 54: Check Measurement

    A leakage test can be performed by briefly kinking the biogas hose. The flow rate in the left "bypass" flowmeter should drop to zero in this case. Record the values measured in the calibration report. After measurement, the device returns to stand-by mode and starts the next measuring process depending on the AUTO/MANUAL setting. 800-01.06.EN SSM 6000 User Manual...

  • Page 55: Maintenance, Repair, Customer Service

    8 Maintenance, repair, customer service The SSM 6000 is a complex electronic measuring device and must hence be handled with care. The manufacturer is solely responsible for the original safety characteristics and features of the device. Any guarantee becomes void if the device is modified in any manner not performed or approved by the manufacturer.
  • Page 56 The analyzer should be checked and calibrated by the manufacturer or qualified technical personnel at least once a year. Defective devices must be taken out of operation and returned to the manufacturer after prior agreement. Pronova Analysentechnik GmbH & Co. KG Groninger Straße 25...

  • Page 57: Status Messages, Trouble-Shooting

    The exhaust air duct is clogged or frozen. Diagnosis is possible by disconnecting the exhaust air hose. The device is defective. 800-01.06.EN SSM 6000 User Manual...

  • Page 58: Warranty Conditions

    The device is defective. If it is not possible to solve the problem, please contact the manufacturer. Pronova Analysentechnik GmbH & Co. KG Groninger Straße 25 13347 Berlin, Germany...

  • Page 59: Appendix

    SSM 6000 APPENDIX 11 Appendix Appendix 800-01.06.EN SSM 6000 User Manual...

  • Page 61: Technical Specifications

    Exhaust air must be discharged into the outside atmosphere in a non-pressurized condition / discharge hoses should be as short as possible Test gas mixture for calibration (example) 40Vol.%. of CO / 300ppm H S / 0 Vol.%. oif O / 800ppm H / rest CH 800-01.06.EN SSM 6000 User Manual...
  • Page 62 5°C (ex-works setting) Condensate pump Hose pump, 16ml/min, Novoprene hose Status displays (LED), alarm at ±3°C System monitoring Characteristic of measuring-gas cooler Ausgangstaupunkt in Abhängigkeit vom Eingangstaupunkt und Volumenstrom 50°C 40°C 30°C 20°C Messgasvolumenstrom in l/h 800-01.06.EN SSM 6000 User Manual...

  • Page 63: Parts Subject To Wear And Tear; Spare Parts

    11.2 Parts subject to wear and tear; spare parts Article No. Description 800 - 0001 Filter set for SSM 6000 (3x 0007 / 1x 0003, 0005 and 0006 / 2x 0002 each) 800 - 0002 Filter mat for housing, 2-layer 800 - 0003...

  • Page 65: Calibration Report Template

    SSM 6000 CALIBRATION REPORT TEMPLATE 11.3 Calibration report template Calibration report template 800-01.06.EN SSM 6000 User Manual...

  • Page 71: Declarations Of Conformity

    11.4 Declarations of conformity EC Declaration of Conformity Manufacturer: Pronova Analysentechnik GmbH & Co. KG Groninger Straße 25 13347 Berlin Germany Product description: SSM 6000 / SSM 6000 LT Determination of CH S, O , CO and H concentration Manufacturer No.:...
  • Page 73 SSM 6000 DECLARATIONS OF CONFORMITY 800-01.06.EN SSM 6000 User Manual...
  • Page 74 SSM 6000 DECLARATIONS OF CONFORMITY 800-01.06.EN SSM 6000 User Manual...
  • Page 75 SSM 6000 DECLARATIONS OF CONFORMITY 800-01.06.EN SSM 6000 User Manual...

  • Page 76: Accessory Connection Cables

    DI 1 - high wire end sleeve (length: 200mm) pink/brown DI 2 - high - Cable ends not conbnected must be white/blue DI 3 - high insulated individually! brown/blue DI 4 - high white/red 12VDC white/blue 800-01.06.EN SSM 6000 User Manual...

  • Page 77: Port 2 Connection Cable

    0.5mm² with gray/brown DO-05 DO-09 wire end sleeve (length: 200mm) white/pink DO-06 DO-11 - Cable ends not conbnected must be pink/brown DO-07 DO-13 insulated individually! white/blue DO-08 brown/blue DO-09 white/red DO-10 white/blue 800-01.06.EN SSM 6000 User Manual...

  • Page 79: Connection Diagrams - Analyzer Versions A / B

    SSM 6000 ANSCHLUSSPLÄNE 11.6 Connection diagrams – Analyzer versions A / B Connection diagrams Analyzer version A 800-01.06.EN SSM 6000 User Manual...
  • Page 93 SSM 6000 ANSCHLUSSPLÄNE Connection diagrams Analyzer version B 800-01.06.EN SSM 6000 User Manual...
  • Page 109 SSM6000 Biogas Analyzer Description of the Profibus Interface...
  • Page 111 Description PROFIBUS interface INTRODUCTION ELECTRICAL TRANSMISSION EQUIPMENT SSM6000 NTERFACE PROPERTIES OF THE US CABLE HIELDING ONNECTOR US TERMINATION ONNECTOR LAYOUT DATA TRANSMISSION ARAMETER DATA ONFIGURATION DATA YCLIC MODE CYCLIC MODE 3.4.1 EAD ACCESS 3.4.2 RITE ACCESS SSM6000 ATA MODULES OF THE ATA TYPES AND DATA FORMAT 3.6.1 FLOAT...

  • Page 113: Introduction

    Description PROFIBUS interface Introduction This technical description deals with the Profibus DP (DP Decentralized Periphery) slave interface of the SSM6000. The correct description is as follows: Profibus-DP: Compliance to IEC 61784 Ed.1:2002 CPF 3/1 Electrical transmission equipment Interface properties of the SSM6000 The SSM6000 comes with a galvanically (optically) isolated Profibus interface according to IEC61784 Ed.1:2002 CPF3/2 (formerly EN50170).

  • Page 114: Bus Termination

    Description PROFIBUS interface Bus termination The PROFIBUS interface of the SSM6000 does not terminate the PROFIBUS at the device end. The SSM6000 does not set the open-circuit level of the bus at the device end. If this is required, the necessary measures must be implemented in the PROFIBUS connector.

  • Page 115: Configuration Data

    Description PROFIBUS interface In the parameter data telegram, the following pattern can appear for example 1: Param. DPV1-1 DPV1-2 DPV1-3 Module parameter P1..P7 Configuration data The configuration data is transmitted in the "special format". The following example refers to CH4: 42 , 83 , 00 , 01...

  • Page 116: Cyclic Mode

    Description PROFIBUS interface Cyclic mode The SSM6000 DP slave features a modular design. The data modules can be combined in any order for cyclic operation. It is not necessary to insert blank modules, and it is possible to select several modules at the same time. The only restriction is that the maximum number of inputs and outputs (as specified in the GSD file) may not be exceeded.

  • Page 117: Data Modules Of The Ssm6000

    Description PROFIBUS interface The same error message is generated if the "Measurement" data module was selected (parameterized) for cyclic data exchange. Otherwise the output value which is output in acyclic mode would be cyclically overwritten. Write access is possible via index 2 only. Write access attempts with another index trigger the "DPV1_ERRCL_ACC_INV_INDEX" error message (error code: 0B0 DS_Write telegram: 0x5F...
  • Page 118 Description PROFIBUS interface Analyzer status The analyzer status indicates whether the SSM6000 is in setup or measuring mode. The values transmitted have the following meanings: Value transmitted Mode 0x01 Setup mode 0x02 Measuring mode Alarms Table as an overview for the bit-coded alarms Alarm type CH4 over CH4 under...

  • Page 119: Data Types And Data Format

    Description PROFIBUS interface Data types and data format The data transmitted via the Profibus is assigned to specific data types which, for their part, are stored in a specific data format. 3.6.1 FLOAT The "float" data type is transmitted as a 32-bit float value. 4 data bytes are required for this purpose. The bytes are stored as follows: Example: Float value: 1234.56...

  • Page 120: Device Address And Id Number

    Description PROFIBUS interface Device address and ID number Device address The device address is used to distinguish between the different devices within a Profibus network. Each device must have a distinct address and all devices must have different addresses. Address changes via the Profibus in the "Wait-Parameter" (WPRM) state are currently not supported by the SSM6000.

  • Page 121: Gsd File

    Description PROFIBUS interface GSD file ;* ================================================================================ * ;* Vendor: Novera Systemtechnik GmbH Groninger Str. 25 13347 Berlin Germany Tel.: +49-30-45029354 FAX.: +49-30-45029355 ;* ================================================================================ * ;* Function: SSM6K ;* Order Number : 43235000-gsd ;* -------------------------------------------------------------------------------- * ;* Author: R. Pandel Tel.: +49-30-45029354 FAX.: +49-30-45029355 ;* -------------------------------------------------------------------------------- *...
  • Page 122 Description PROFIBUS interface MaxTsdr_500=15 MaxTsdr_1.5M=20 MaxTsdr_3M=35 MaxTsdr_6M=50 MaxTsdr_12M=95 ;============================================================================== ;==== Slave specific values =================================================== ;============================================================================== Slave_Family = 3@PRONOVA@SSM6000 Implementation_Type "VPC3+" Bitmap_Device "ssm_AFFE" Freeze_Mode_supp=1 Sync_Mode_supp=1 Fail_Safe=1 Auto_Baud_supp=1 Set_Slave_Add_supp=0 Min_Slave_Intervall=20 Modular_Station=1 Max_Module=10 Modul_Offset=1 Max_Input_Len=51 Max_Output_Len=1 Max_Data_Len=52 Max_Diag_Data_Len=17 ;============================================================================== ;==== User-Prm-Data =========================================================== ;==============================================================================...
  • Page 123 Description PROFIBUS interface Module="Temp (float) " 0x42,0x83,0x00,0x06 Ext_Module_Prm_Data_Len=5 Ext_User_Prm_Data_Const(0)=0x05,0x81,0x00,0x00,0x06 EndModule Module="Status (Byte) " 0x42,0x00,0x00,0x07 Ext_Module_Prm_Data_Len=5 Ext_User_Prm_Data_Const(0)=0x05,0x81,0x00,0x00,0x07 EndModule Module="Alarm (Byte) " 0x42,0x00,0x00,0x08 Ext_Module_Prm_Data_Len=5 Ext_User_Prm_Data_Const(0)=0x05,0x81,0x00,0x00,0x08 EndModule Module="Messen (Byte) " 0xC1,0x00,0x00,0x09 Ext_Module_Prm_Data_Len=5 Ext_User_Prm_Data_Const(0)=0x05,0x81,0x00,0x00,0x09 EndModule Module="AI (WORD) " 0x42,0x4A,0x00,0x0A Ext_Module_Prm_Data_Len=5 Ext_User_Prm_Data_Const(0)=0x05,0x81,0x00,0x00,0x0A EndModule ;============================================================================== ;==== DPV1 KEY WORDS ========================================================== ;============================================================================== DPV1_Slave C1_Read_Write_supp...
