Specifications - ADC RealFlex Drop Cables Specification Sheet

OmniReach
RealFlex™ MDU Drop Cables
Features and Benefits
• Bend radius as small as 7.5 mm without changing
cable characteristics
• Greatly reduces risk to bend induced insertion
loss created during installation
• Indoor/Outdoor, Plenum and Riser cable
options available
• Rugged 3 mm cable jacket construction

Specifications

environmental CharaCteristiCs
storage temperature:
operating temperature:
installation temperature:
meChaniCal CharaCteristiCs
number of Fibers:
maximum tensile load
short term load:
long term load:
minimum Bend radius
installed:
loaded:
1 For cable lengths that are ten feet or less, the Storage and Operating Temperature specifications are -55º to +75º C
)
(-67 to +167º F
1550 nm
reference
stapled 3mm realFlex™ mDU Drop Cables
w w w . a d c . c o m
FTTX Solutions
®
indoor/outdoor Cable
-40° to +75° C
(-40° to +167° F)
-40° to +75° C
(-40° to +167° F)
-30° to +50° C
(-22° to +122° F)
indoor/outdoor,
riser and Plenum Cable
1
440 N (100 lbs.)
220 N (50 lbs.)
.295 in. (.75 cm)
1.18 in. (3.0 cm)
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
• G.657 Table A and B compliant
• Two cable configurations available: connectors
on both ends or connector on one end
• Spooling options: end with connector pulled first
or end without connector pulled first
• Ivory cable color helps distinguish cable
in the field
riser Cable
1
-40° to +70° C
(-40° to +158° F)
-20° to +70° C
(-4° to +158° F)
0° to +50° C
(+32° to +122° F)
dBr
standard Fiber
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Plenum Cable
-40° to +70° C
(-40° to +158° F)
0° to +70° C
(+32° to +158° F)
+10° to +50° C
(+50° to +122° F)
reduced Bend radius Fiber
2
