  • Page 1 HBLD3-D Electric Wheelchair Instruction Manual SunTech UK Ltd (t/a eFOLDi)

  • Page 2: Safety Precautions

    Introduction: Thank you for purchasing our eFOLDi HBLD3-D electric wheelchair. This ultra- light electric wheelchair has been carefully researched and developed to be light, energy efficient and easy to operate. Please read this manual carefully before use, so that you are familiar with all the various functions, and understand the required maintenance, this will ensure that the wheelchair remains in good condition and is safe to use.

  • Page 3: Emc Warning Statement

    Do not use electric wheelchairs on sandy or soft ground. Avoid driving on slopes greater than 8 degrees or over obstacles greater than 4 cm in height. Do not disassemble or change parts of the electric wheelchair or replace parts not manufactured by the manufacturer without manufacturer’s permission.
  • Page 4 Classification: According to the classification of medical devices, this electric wheelchair belongs to the ward nursing equipment and appliances (6856) management category for class 2. Classified by operation mode: continuous operation. According to the number of users: single use of equipment. Classification by anti-electric shock: internal power supply.
  • Page 5 HBLD3-D performance configuration Use ambient temperature: - 25°- + 50° Product type: indoor Weight capacity: 135kg (21st) Power supply: 24 V ,5.2 AH Maximum speed: ≤6km/h Motor power: 300W x 2 Noise: < 65DB Full power range: 20km Maximum gradient: 8°...
  • Page 6 How to open the wheelchair: Once removed from the packaging, place the wheelchair on a stable surface. Place your hands on either side of the folded seat and push apart until the seat is open at 90 degrees and you hear a distinct "click"...
  • Page 7 Insert the joystick into the fixing frame and insert the wire into the wire clips. Insert point When in use, please press the " l " switch (“ l “ means POWER ON. If not in use, please press the " O " switch (" O "means POWER OFF).
  • Page 8 Before getting into an electric wheelchair, please check the following: Make sure the manual brake is working. Make sure the battery is installed correctly. Make sure the joystick is working. After you get into the electric wheelchair, please fasten your seat belt first then switch on the power by pushing the power button.
  • Page 9 When parking on a ramp, the electromagnetic brake may not always be strong enough, always use the manual brake in conjunction with the electromagnetic brake The user should choose the speed of the electric wheelchair according to his/her physical condition and road condition. Free wheel mode: After turning off the power switch button on the controller, press the black circular button on the controller box, and an indicator light will appear on the...
  • Page 10 Charging: Switch on the power, the power indicator light in the front row will be on, full power will show 5 lights (2 red, 1 yellow, 2 green). When the two red lights are flashing, this indicates that the battery requires charging. Remove the battery and plug the charger into the battery charging port.

  • Page 11: Troubleshooting

    How to fold the wheelchair: With the wheelchair on a stable surface, lift the footplate into it's upright position. Place both hands onto the black handles underneath either side of the seat and pull the round disk and push the handle firmly away from you.

  • Page 12: Maintenance

    Maintenance: weekly monthly every 3 every 6 Check cycle daily months months Battery ✔ ✔ Power connection Tyre pressure ✔ Hand brake ✔ ✔ Battery terminal ✔ Wiring ✔ Exterior surface ✔ Tyre surface ✔ Electromagnetic brake Cover and back of chair: remove the cover and back of chair. Wash the cover and back of chair with warm water and diluted soapy water. General maintenance: do not use lubricant to maintain the wheelchair.

  • Page 13: Limited Warranty

    Unplanned product obsolescence after the Warranty expires. Precautions: First of all, thank you for purchasing our eFOLDi electric wheelchair. Second, please pay attention to the following matters in daily use: Do not disassemble the battery. In case of serious battery impact, please contact the manufacturer immediately.

  • Page 14: Waste Disposal

    Waste disposal: If the battery needs to be recycled or discarded, be sure to use tape to insulate part of the electrode. Contact with other metals will lead to battery overheating, rupture or fire. Send the used batteries to the manufacturer's maintenance service centre only.
  • Page 15 Maintenance record Maintenance record 1 Issues Date Description Maintenance record 2 Issues Date Description handling： Maintenance record 3 Issues Date Description handling： Comments：...
  • Page 16 SunTech UK Ltd (t/a eFOLDi) 48 Holmethorpe Avenue Redhill, RH1 2NL 0044(0)20 3143 5168...
