ANC-100e User Manual
ANC-100e
Ethernet to Data Highway Plus
Adapter
User Manual
About ANC-100e
The ANC-100e allows you to connect a computer on an Ethernet network to a DH+ network and
communicate with various DH+ enabled devices such as Allen Bradley's PLC5, SLC5/04, SLC5/05,
ControlLogix series and other devices which might support Allen Bradley DH+ network connectivity.
ANC-100e is designed to work utilizing the Ethernet/IP network driver available in most industrial
communication software suites, such as Allen Bradley RSLinx Classic/Gateway/Enterprise and alike. And
its auto-configuration features provide a quick and easy connection, as cable polarity, node number and
baud rate can be auto-detected and auto-configured. For more information on properly configuring your
software suite of choice to work with ANC-100e, please see the corresponding chapter of this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Highway Plus ANC-100e and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Automation Networks Highway Plus ANC-100e

Summary of Contents for Automation Networks Highway Plus ANC-100e

  • Page 1 ANC-100e User Manual ANC-100e Ethernet to Data Highway Plus Adapter User Manual About ANC-100e The ANC-100e allows you to connect a computer on an Ethernet network to a DH+ network and communicate with various DH+ enabled devices such as Allen Bradley’s PLC5, SLC5/04, SLC5/05, ControlLogix series and other devices which might support Allen Bradley DH+ network connectivity.

  • Page 2: Table Of Contents

    Automatic Polarity detection................. 9 Main Configuration Window ..............9 Device Password ................10 Firmware Upgrade ................10 Statistics ..................... 14 HMI…………………………………………………………………………..15 Language ................... 16 ........16 ESET TO EFAULT ACTORY ETTINGS .......... 17 EVICE ECHNICAL PECIFICATIONS ©Automation Networks & Solutions LLC. 2016...

  • Page 3: User Manual

    IP address is not used on your network by any other IP enabled device, please skip this step. 1. Open Window’s Control Panel 2. Click on “Network and Internet” 3. Click on “Network and Sharing Center” 4. Click on “Change adapter settings” ©Automation Networks & Solutions LLC. 2016...
  • Page 4 9. Select the option “Use the following IP address” 10. Configure the adapter to use following settings: IP address: 192.168.0.1 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.0.1 11. “DNS server” settings blank 12. Click “OK” button ©Automation Networks & Solutions LLC. 2016...
  • Page 5 ANC-100e User Manual 5 Ethernet to DH+ Adapter 13. Click “OK” button to close “Local Area Connection” properties window ©Automation Networks & Solutions LLC. 2016...

  • Page 6: Using Anc-100E

    LED labeled “Diag” indicated the current status of the ANC-100e device on the DH+ network: • “LED Solid Red” indicates that the device is not currently associated on a DH+ network. • “LED Solid Green” indicates that the device is associated on the DH+ network ©Automation Networks & Solutions LLC. 2016...

  • Page 7: Accessing Anc-100E User Interface

    3. Enter the username and password in the corresponding fields. By default, the username is set to “admin” and password to “password” 4. Click “OK” button. 5. If you entered the correct login credentials, you will be presented with the main configuration window. ©Automation Networks & Solutions LLC. 2016...
  • Page 8 ANC-100e User Manual 8 Ethernet to DH+ Adapter ©Automation Networks & Solutions LLC. 2016...

  • Page 9: Configuration And Interface

    By default, device is set to automatic DH+ speed detection; please see the description of this feature at the beginning of this chapter ©Automation Networks & Solutions LLC. 2016...

  • Page 10: Device Password

    “192.168.0.230” 2. Enter the username and password and click “OK” button. If you have changed password (see above), use new one. Default username is set to “admin” and password is set to “password” ©Automation Networks & Solutions LLC. 2016...
  • Page 11 6. The following dialog will appear... 7. Wait 5 seconds for the device to reboot and press “OK” button 8. Device will enter the FW upgrade mode and the following page will be displayed in your browser window: ©Automation Networks & Solutions LLC. 2016...
  • Page 12 18. Wait 10 seconds and press the “Return” button to access the device configuration interface • Firmware upgrades will ensure that all the currently configured device settings are preserved and there is no need to reconfigure the device after the firmware upgrade. ©Automation Networks & Solutions LLC. 2016...
  • Page 13 User Manual 13 Ethernet to DH+ Adapter In case where the user might have entered the firmware upgrade mode accidently, please press the “Reboot” button and the device will reboot into the normal operating mode. ©Automation Networks & Solutions LLC. 2016...

  • Page 14: Statistics

    Statistics screen provides a real time statistics data about the health of the device and the network it is operating on. This screen also provides the status of the devices that are connect to the DH+ network. ©Automation Networks & Solutions LLC. 2016...

  • Page 15: Hmi

    IP address assigned to SLC5/04 = 192.168.0.231 *1 If your SLC or PLC is in node 0 please use 00 in the HMI configuration. * 2 Always assign an IP address that is not being used in the network. ©Automation Networks & Solutions LLC. 2016...
  • Page 16 DH+ node In the Panel View configuration, you must add a PLC or SLC device from the “Ethernet SLC devices” or “Ethernet PLC devices” folders, depending on what is the target on the DH+ network. ©Automation Networks & Solutions LLC. 2016...

  • Page 17: Language

    4. Device will reboot restoring its factory default settings IMPORTANT: Factory default settings for the device are: IP address 192.168.0.230 Network Mask 255.255.255.0 Default Gateway 192.168.0.1 DHCP DH+ node AUTO DH+ speed AUTO Interface Language English Username admin Password password ©Automation Networks & Solutions LLC. 2016...

  • Page 18: Device Technical Specifications

    400V (continuous), tested at 2000V for 60 s Typical Power Consumption: 0.9 W Maximum Power Consumption: 1.0 W Operating Temperature: -40 to +85⁰ C Storage Temperature: -40 to+100⁰ C Humidity: 0 to 98% Dimensions: 86 x 57 x 27 mm ©Automation Networks & Solutions LLC. 2016...
  • Page 19 ANC-100e User Manual 19 Ethernet to DH+ Adapter Mounting: Desktop or DIN-rail mounting Automation Networks and Solutions LLC http://automation-networks.com info@automation-networks.com ©Automation Networks & Solutions LLC. 2016...
