TABLE OF CONTENTS
SPECIFICATIONS.............................................................2
LOCATION OF CONTROLS ..........................................4
LOCATION OF CONTROLS PARTS LIST ..................5
EXPLODED VIEW 1 .........................................................6
EXPLODED VIEW 2 .........................................................7
EXPLODED VIEW 3 .........................................................8
EXPLODED VIEW PARTS LIST .....................................9
PARTS LIST......................................................................10
CHECKING THE VERSION NUMBER.......................15
USERS DATA SAVE AND LOAD................................15
RESTORING THE FACTORY SETTINGS...................16
SYSTEM SOFTWARE UPDATE PROCEDURE .........17
TEST MODE.....................................................................17
BLOCK DIAGRAM.........................................................20
CIRCUIT BOARD(MAIN) .............................................22
Copyright © 2002 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
CIRCUIT DIAGRAM(MAIN 1/4) ................................24
CIRCUIT DIAGRAM(MAIN 2/4) ................................26
CIRCUIT DIAGRAM(MAIN 3/4) ................................28
CIRCUIT DIAGRAM(MAIN 4/4) ................................30
CIRCUIT BOARD(SW SHEET ASSY) ..........................32
CIRCUIT BOARD(ANALOG).......................................34
CIRCUIT DIAGRAM(+5V BOARD).............................36
CIRCUIT DIAGRAM(SW) .............................................38
ERROR MESSAGES ........................................................40
CDI-BR-1..........................................41
SPECIFICATIONS...........................................................41
PARTS LIST......................................................................42
INSTALLING THE CDI-BR-1........................................43
The wiring exchange method ........................................44
17058069E0
SERVICE NOTES
Issued by RJA
Printed in Japan (0800) (NB)
BR-1180
