- Page 1 Midaswei Trading Co., Ltd. Midaswei MW-05 Ionizer Fan Instruction Manual Address: Room A, 9F, No.33, Sec.2 Roosevelt Road, Taipei 10643, Taiwan, R.O.C Tel: 886-2-2396-5048 Contact e-mail: midas001@midaswei.com MW-05 Revision B2...
- Page 2 Midaswei Trading Co., Ltd. A. Overview Ion quantity adjustment switch Power supply indicator PO W ER High voltage abnormality indicator Power switch A LA R M High voltage normality indicator ION ADJ H .V MW-05 Ion quantity indicator MW-05 Rev:B2...
-
Page 3: Ac Adapter Installation
‘H.V.’ LED become light up. The ion number is zero in initial stage. 2.2 First stage Push the ion quantity adjustment switch (ION ADJ) in the initial stage, MW-05 will enter into first stage. The fan keeps spinning and the buzzer will beep once. The ‘POWER’... -
Page 4: Abnormal Condition
Midaswei Trading Co., Ltd. 2.4 Third stage Push the ion quantity adjustment switch (ION ADJ) in the second stage, MW-05 will enter into second stage. The fan keeps spinning and the buzzer will beep once. The ‘POWER’ LED,‘H.V.’ LED and right-hand side two LEDs of ion quantity indicator become light up. - Page 5 Midaswei Trading Co., Ltd. 4. Indication/Function Stage Ion quantity LED indication Buzzer POW ER Power ON zero Operation Stop A LARM (Initial stage) H .V POW ER Largest Operation Beep stage A LARM H .V POW ER stage Secondly large...
-
Page 6: Cleaning And Maintenance
Midaswei Trading Co., Ltd. C. Cleaning and Maintenance 1. Clean the discharge needle by a soft brush at least once a week. Do NOT clean the discharge needle by any hard object, or the needle tip will be damaged. 2. If the needle tip is damaged, replace the discharge needle unit immediately to maintain proper function. -
Page 7: Specification
Midaswei Trading Co., Ltd. D. Specification Name MW-05 Accessory AC adapter: Power supply voltage Input: 100Vac~240Vac, Output: DC24V Input power High voltage output AC 4400V Static charge removal time ±1KV→±100V within 1 sec at distance of 30cm Balance Voltage ±2V at 30cm central position Air flow 2.84 m... - Page 8 Midaswei Trading Co., Ltd. E. Dimensions Unit: mm MW-05 Rev:B2...
-
Page 9: Safety Precaution
4. Do NOT use the ionizer fan in a flammable or explosive environment. 5. Do NOT replace any part or attempt to self-repair. 6. Under normal use and proper care, we provide one-year warranty for MW-05. However, consumables (discharge needles, filter cotton, etc.) are NOT within warranty. - Page 10 Midaswei Trading Co., Ltd. G. Set-up Pin-base of MW-05 Step 1. Open fan cover Open Open Step 2. Pick-up the screw and pin-base Fixed point of pin-base Pin-base * The needle tip is very sharp. Pay attention to Screw avoid being stabbed.
- Page 11 Midaswei Trading Co., Ltd. . Packaging Each Ionizer set includes a MW-05, a Power adaptor and a Power cord. Place an Ionizer set in the 284mm*253mm*110mm paper box。 4 PCS 284mm*253mm*110mm paper box is 1 stack。 497mm*337mm*293mm carton can be put into 4 paper box.
- Page 12 Midaswei Trading Co., Ltd. I. Attachment 1 1. The input voltage and current difference MW-05 and A vendor： a. The Positive and negative voltage difference：MW-05 △1V ；A vendor △1.2V。 b. The Positive and negative current difference：MW-05 △7.6mA ；A vendor ...
- Page 13 Midaswei Trading Co., Ltd. J. Attachment 2 The decay ability of MW-05 measured on 2018/11/13. MW-05 Rev:B2...
- Page 14 Midaswei Trading Co., Ltd. K. Attachment 3 The decay capacity compared MW-05 with Japanese brand. MW-05 Rev:B2...
