- Page 1 Midaswei Trading Co., Ltd. 金威貿易有限公司 MW-Series Ionizer fan Operating Instructions for replacing the electrode needle hub...
- Page 2 A. Overview Fan Cover P O W ER A LA R M ION AD J H .V MW-05 B. Instructions Step 1. Unplug the power supply and lay the MW-Series Ionizer Fan on a flat surface. Step 2. Push the latches on both sides of the Fan Cover (the position of the blue arrow in the left figure) and remove the Fan Cover.
- Page 3 Step 3. After removing the Fan Cover, as shown in the left figure. Step 4. Use a Phillips screwdriver to remove the electrode needle hub unit. Step 5. Replace MW-DN01 to new product. C. Attention 1. The tip of the electrode needle is sharp. Be careful in installation to prevent stab wounds.
- Page 4 E. Specification of Outer Case The electrode needle is covered with 2 pieces of foams and the sides are fixed with tape. Place the 2PCS electrode needle hub in the 110mm*110mm*35mm paper box. 110mm*110mm*35mm carton 7 pcs is 1 stack. 251mm*242mm*270mm carton can be put into 28pcs carton.
