Summary of Contents for Midaswei MW-05A DUAL
- Page 1 Midaswei Trading Co., Ltd. Midaswei MW-05A DUAL Ionizer Fan Instruction Manual Address: Room A, 9F, No.33, Sec.2 Roosevelt Road, Taipei 10643, Taiwan, R.O.C Tel: 886-2-2396-5048 Contact e-mail: midas001@midaswei.com Revision 5...
- Page 2 Midaswei Trading Co., Ltd. A. Overview Introduction: Power supply indicator Ion quantity adjustment switch Fan speed adjuster Power switch High voltage abnormality indicator High voltage normality indicator Ion quantity indicator MW-05A Dual Rev:5...
-
Page 3: Ac Adapter Installation
Midaswei Trading Co., Ltd. B. Operating instructions MW-05A DUAL is an Ionizer with two MW-05A ionizer fans, it has independent five-stage adjustable ions quantity, independent Adjustable air volume and an independent protection of high voltage output abnormal. By using with the accessory AC adapter, MW-05A DUAL is suitable for 110Vac/220Vac supply voltage. - Page 4 2.4 Third stage Push the ion quantity adjustment switch (ION ADJ) in the second stage, MW-05A DUAL will enter into second stage. The fan keeps spinning and the buzzer will beep once. The ‘POWER’ LED,‘H.V.’ LED and right-hand side two LEDs of ion quantity indicator become light up.
-
Page 5: Abnormal Condition
3.2 When the foreign object contacts the discharge needle unit, ‘ALARM’ LED becomes light up and the buzzer sounds. If this abnormal condition is not solved within 1 minute, MW-05A DUAL will be also locked. 3.3 Holding the ion quantity adjustment switch (ION ADJ), the buzzer sounds until release the ion quantity adjustment switch. -
Page 6: Cleaning And Maintenance
Midaswei Trading Co., Ltd. C. Cleaning and Maintenance 1. 1. Clean the discharge needle by a soft brush at least once a week. Do NOT clean the discharge needle by any hard object, or the needle tip will be damaged. -
Page 7: Specification
Midaswei Trading Co., Ltd. D. Specification Name MW-05A DUAL Accessory AC adapter: Power supply voltage Input: 100Vac~240Vac, Output: DC24V Input power High voltage output AC 4400V ±1KV→±100V within 1 sec at distance of 30cm Static charge removal time central position Balance Voltage ±2V at 30cm central position... - Page 8 Midaswei Trading Co., Ltd. E. Dimensions Unit: mm MW-05A Dual Rev:5...
-
Page 9: Safety Precaution
9. The ionizer fan generates ozone in operation. Ventilation is required when operating in a confined space. 10. Midaswei ionizer fan is designed for general industrial and indoor use. They are not suitable for outdoor use as well as not suitable for environments that cause life or property safety, such as nuclear power plants, aircrafts, ships or hospitals. - Page 10 Midaswei Trading Co., Ltd. G. Set-up Pin-base of MW-05A DUAL Step 1. Open fan cover Open Open Step 2. Pick-up the screw and pin-base Fixed point of pin-base Pin-base * The needle tip is very sharp. Pay attention to Screw avoid being stabbed.
- Page 11 Midaswei Trading Co., Ltd. H. Packaging Each Ionizer set includes tow MW-05 A, a MW-350 Stand, a 1to2 output Y-type DC cable, a Power adaptor and a Power cord. Place an Ionizer set in the 470mm*140mm*250mm paper box。 2 PCS 470mm*140mm*250mm paper box is 1 stack。...
- Page 12 Midaswei Trading Co., Ltd. I. Attachment 1 1. The input voltage and current difference MW-05A DUAL and A vendor： a. The Positive and negative voltage difference： MW-05A DUAL △1V ；A vendor △1.2V。 b. The Positive and negative current difference：...
- Page 13 Midaswei Trading Co., Ltd. J. Attachment 2 The decay ability of MW-05 DUAL (measured on 2018/10/17). MW-05A Dual Rev:5...
