Photoneo MotionCam-3D M Quick Start Manual

For engineering sample
Hide thumbs Also See for MotionCam-3D M:

Advertisement

Quick Links


MotionCam-3D
Quick Start Guide for Engineering Sample



Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MotionCam-3D M and is the answer not in the manual?

Questions and answers

Summary of Contents for Photoneo MotionCam-3D M

  • Page 1   MotionCam-3D  Quick Start Guide for Engineering Sample     ...
  • Page 2 Photoneo has started to sell ​ e ngineering samples​ of the MotionCam-3D while it is still in the development stage. This  allows customers to test out the camera’s potential and to prepare for significant advances in the field of 3D capturing, ...
  • Page 3 15 Million points per second  Scanning Range and Point Size      Figure 1: Scanning volume of the MotionCam-3D.    The point size is the average distance between two measured 3D points.   support@photoneo.com MotionCam-3D - Quick Start Guide for Engineering Sample 3/8 ...
  • Page 4 NVIDIA GeForce RTX2080 TI or better  Software  MotionCam-3D is operated via PhoXi Control version 1.3. Download PhoXi Control for:  Windows:   ■ www.photoneo.com/files/installer/PhoXi/1.3.2/PhotoneoPhoXiControlInstaller-1.3.2-win64.exe  Ubuntu 16:  ■ www.photoneo.com/files/installer/PhoXi/1.3.0-cam-alpha/PhotoneoPhoXiControlInstaller-1.3.0-Ubuntu16-gcc55-3d Cam-@2610ddf.run.tgz  This Quick Start guide assumes that the reader is familiar with version 1.2 of the PhoXi Control application. We are going to ...
  • Page 5 All the other modes enable high-FPS camera performance with the ability to scan moving objects. Please note that the  following scanning parameters are unavailable when any of the high-FPS camera modes is selected: Coding Strategy,  Coding Quality, and recognition of Marker Space.  support@photoneo.com MotionCam-3D - Quick Start Guide for Engineering Sample 5/8 ...
  • Page 6 Figure 3: The sub-pixeling diagram of Modes 3 and 4. The red  results.  points are direct measurements whereas the blue points are  secondary measurements. On the right is the resulting point cloud  of a flat plane.  support@photoneo.com MotionCam-3D - Quick Start Guide for Engineering Sample 6/8 ...
  • Page 7 Computation of normals is by default turned off. The following utility can be used to turn the  computation of normals ON:  www.photoneo.com/files/utils/EnableNormals.zip  Please contact ​ s upport@photoneo.com​ if you require assistance.  Hardware Trigger & Daisy Chain  It is possible to set up several MotionCam-3D cameras to work synchronously by using the hardware trigger functionality ...
  • Page 8 05/2020    Photoneo s.r.o.  Plynárenská 1  82109, Bratislava  Slovakia  support@photoneo.com MotionCam-3D - Quick Start Guide for Engineering Sample 8/8 ...
