- Page 1 Sun Gold Power Co.,Ltd www.sungoldpower.com...
- Page 2 Sun Gold Power Co.,Ltd www.sungoldpower.com ARC-200 110/220V We are still constantly improving this welder, therefore, some parts of this welder may be changed in order to achieve the better quality, but the main functions and operations will not be alternated and changed.
-
Page 3: Table Of Contents
Sun Gold Power Co.,Ltd www.sungoldpower.com Table of Contents Safety ................................General Description ............................. Main Parameters ............................Electric Block Diagram ..........................Operation Control and Description ......................Installation Debugging and Operation ......................Caution ................................. Maintenance ..............................Troubleshooting ............................Exploded Drawing ............................ -
Page 4: Safety
Sun Gold Power Co.,Ltd www.sungoldpower.com 1. Safety Welding is dangerous, and may cause damage to you and others, so take good protection when welding. For details, please refer to the operator safety guidelines in conformity with the accident prevention requirements of the manufacturer. - Page 5 Sun Gold Power Co.,Ltd www.sungoldpower.com Hot work piece may cause severe scalding. Do not contact hot work piece with bare hands. ● Cooling is needed during continuous use of the welding torch. ● Magnetic fields affect cardiac pacemaker. Pacemaker users should be away from the welding spot before medical consultation.
-
Page 6: General Description
Sun Gold Power Co.,Ltd www.sungoldpower.com 2. General Description Advanced DC inverter technology High inverter frequency greatly reduces the volume and weight of the welder. ● Great reduction in magnetic and resistance loss obviously enhances the welding efficiency and energy saving effect. -
Page 7: Main Parameters
Sun Gold Power Co.,Ltd www.sungoldpower.com 3. Main Parameters Technical parameters table: ARC-200 110/220V 1P AC 110V/220V, 50/60Hz 110V 220V 160A/26.4V 200A/28V 20~160 20~200... -
Page 8: Electric Block Diagram
Sun Gold Power Co.,Ltd www.sungoldpower.com 4. Electric Block Diagram... -
Page 9: Operation Control And Description
Sun Gold Power Co.,Ltd www.sungoldpower.com 5. Operation Control and Description 1) Current display meter 2) Overheating LED : Overheating LED “on” indicates the temperature inside machine is too high. 3) Power LED : Power LED “on” indicates the power switch of machine is on. -
Page 10: Installation Debugging And Operation
Sun Gold Power Co.,Ltd www.sungoldpower.com 6. Installation Debugging and Operation Warning Please install the machine strictly according to the following steps. The protection class of this machine is IP21S, so avoid using it in rain. Before using, please make sure the input voltage is in voltage range (110V/220V). Otherwise, the machine will be damaged. -
Page 11: Caution
Sun Gold Power Co.,Ltd www.sungoldpower.com 7. Caution 7.1 Working environment 1) The product shall be operated under dry environment with normal humidity under 90%. 2) The temperature of working environment should be between -10°C and 40°C. 3) Avoid welding in the open air unless sheltered from sunlight and rain. Keep it dry anytime and do not place it on wet ground or in puddles. -
Page 12: Maintenance
Sun Gold Power Co.,Ltd www.sungoldpower.com 8. Maintenance Warning This machine will produce electric and magnetic fields, so the operator should ensure proper protection and ● screening while using it. Earth leakage-circuit breaker should be used with this machine. ● During operation, DO NOT pull out or insert any plugs or cables. It can lead to fatal danger and cause dam- ●... -
Page 13: Troubleshooting
Sun Gold Power Co.,Ltd www.sungoldpower.com 9. Troubleshooting Warning Experimentation and careless maintenance may lead to more problems to the machine. This will make pro- fessional diagnosis and repair more difficult. When the machine is open, there may be exposed connections containing life-threatening voltages. -
Page 14: Exploded Drawing
Sun Gold Power Co.,Ltd www.sungoldpower.com 10.Exploded view Upright supports Plastic windshield Rectifier bridge Small control board Iron panel Switch Output board...
