- Page 1 REFLEX GYRO SPRINT-IQ™ Quick User Guide MODE: North Seeking Multishot SOFTWARE V3.2.33 IMDEXHUB-IQ™ ENABLED reflexnow.com © Imdex Limited November 2018...
- Page 2 This publication is subject to change without notice. Determination of the suitability of any information or product for use contemplated by any user, and the manner of that use is the sole responsibility of the user. REFLEX GYRO SPRINT-IQ™ REFLEX™...
- Page 3 | SET UP REFLEX GYRO SPRINT-IQ™ Check batteries Set up Wi-Fi on Tap to launch the tablet SPRINT-IQ The Projects screen displays Successful login displays username © Imdex Limited November 2018 104121 RTI-MAN-0170 V1...
- Page 4 | SET UP REFLEX GYRO SPRINT-IQ™ or select a project or search Type the first few letter of the Drillhole name (scroll or filter) Ensure the correct latitude is entered. © Imdex Limited November 2018 104121 RTI-MAN-0170 V1...
- Page 5 | INITIALISE REFLEX GYRO SPRINT-IQ™ Select North Seeking Multishot Enter Depths Enter Survey Start Depth: Enter the ground level or any point to start Enter Survey Interval: The number of metres or feet for each measurement Survey Mode: Select North Seeking Refer-...
- Page 6 Connect the USB to the tablet SPRINT-IQ™ Ensure you have allowed enough time for theREFLEX GYRO SPRINT-IQ™ to be attached to the swivel and be ready to commence a survey. If using the ROTA-LOCK OVERSHOT, the battery must be disconnected before initialising and commencing a new survey.
- Page 7 | SURVEY REFLEX GYRO SPRINT-IQ™ Place tool into Stop and wait Measure next survey position for the Survey (There is also an opportunity to change depth, interval, mode and direction) IIIII__II When completed © Imdex Limited November 2018 104121 RTI-MAN-0170 V1...
- Page 8 | SURVEY REFLEX GYRO SPRINT-IQ™ Connect the tablet to the REFLEX GYRO SPRINT-IQ™ and commence download Surveys are listed Upload to IMDEXHUB-IQ™ © Imdex Limited November 2018 104121 RTI-MAN-0170 V1...
- Page 9 | EXPORT REFLEX GYRO SPRINT-IQ™ © Imdex Limited November 2018 104121 RTI-MAN-0170 V1...
- Page 10 Compatibility [[[Undefined variable Variables.ProductName_RL]]] Maintenance & Servicing No user serviceable parts inside. Authorised Accessories Only REFLEX™ approved accessories can be used. Symbols WARNING: Indicates a potentially lethal PPE Gloves hazard. Failure to observe a warning may result in severe injury or death.
