How to Install Compression Card
on OnDemand Switch 3 XL
March 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OnDemand Switch 3 XL and is the answer not in the manual?

Questions and answers

Related Manuals for Radware OnDemand Switch 3 XL

Summary of Contents for Radware OnDemand Switch 3 XL

  • Page 1 How to Install Compression Card on OnDemand Switch 3 XL March 2011...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SCOPE ................................ 3 REQUIRED TOOLS ............................ 3 KIT CONTENTS ............................4 SAFETY ..............................6 INSTRUCTIONS ............................7 ..................... 7 ISASSEMBLY AND PENING THE EVICE ..............13 NSTALLATION OF OMPRESSION ARD AND SSEMBLY .............................. 21 AFETY & C ......................

  • Page 3: Scope

    This document describes the procedure of installing a compression card in ODS-3 XL model. 2 Required Tools Tools Pictures Notes Screwdriver model Not supplied by ): PH1 Radware. size Electric Screwdriver, Not supplied by Type: DRILL & Radware. DRIVER EY 6220 Optional...

  • Page 4: Kit Contents

    3 Kit Contents Tools Pictures Notes Compression Card Qty.:1 including Bracket Supplied by Radware. Screw Qty.:2 Supplied by Radware.
  • Page 5 Tools Pictures Notes ESD Protection Kit, Supplied by Model: 3M-2209. Radware.

  • Page 6: Safety

    4 Safety Before any activities are performed please verify that the device power cable is disconnected. No maintenance should be performed while device is connected to electric current. Any person handling the devices should wear ESD protection (wrist strap or ankle strap, etc.). Table or any other surface that the device is placed upon, should be ESD protected (table top cover and button).

  • Page 7: Instructions

    5 Instructions 5.1 Disassembly and Opening the Device 5.1.1. Place the device on a firm clean surface. It is recommended that the table surface is covered by padding material (to avoid damage to the device's paint).
  • Page 8 5.1.2. Using the screwdriver, remove the 2 screws from the top, holding the device cover in place.
  • Page 9 5.1.3. Remove 3 screws form the right side of the device. Back...
  • Page 10 Middle Front...
  • Page 11 5.1.4. Repeat the same action (removal of 3 screws) on the left side of the device. 5.1.5. After removal of 2 screws from the top and 3 screws from each side (total of 8 screws), slide the top cover backwards.
  • Page 12 5.1.6. After the cover was pushed back over 10 cm, pull the cover up and remove it from the device.

  • Page 13: Installation Of Compression Card And Assembly

    5.2 Installation of Compression Card and Assembly 5.2.1. Locate the compression card slot.
  • Page 14 5.2.2. A close-up from the rear shows that the lower slot is taken by another card. This means that the compression card will be installed in the top slot. 5.2.3. Remove the card from its package and insert the card into the slot. Verify that the shape of the connector matches the shape of the socket.
  • Page 15 5.2.4. Push the card until the connector is fully inserted into the socket and the bracket connected to the card touches the vertical bracket connected to the chassis. 5.2.5. Use your finger to gently align the screw holes on both brackets.
  • Page 16 5.2.6. Use a screwdriver and one of the screws provided in the kit to connect both brackets and secure the card in its place.
  • Page 17 5.2.7. Place the cover on top of the device. About 5 cm of the cover should be placed behind the device (so the cover can slide into place). 5.2.8. Slide the cover forward until it is locked in place.
  • Page 18 5.2.9. Tighten the two screws on the top cover.
  • Page 19 5.2.10. Close the screws on the right side of the device. Back...
  • Page 20 Middle Front...

  • Page 21: Safety

    5.2.11. Repeat the process by tightening the screws on the left side of the device. 5.2.12. A total of 8 screws should be used: two on top, three on the right side and three on the left side. 5.3 Safety 5.3.1.

  • Page 22: Troubleshooting

    5.5 Troubleshooting 5.5.1. It is recommended that you retrace your steps according to this procedure. 5.5.2. If repeating this procedure did not solve your problem please contact the Radware Technical Assistance team (support@radware.com).

This manual is also suitable for:

Ods-3xl
