4. Fully remove the blade screw and washers
the blade
6
to disengage it from the connection rod
pull the blade out of the trimmer.
5. Remove the top connection rod
front and back and angling it so it rotates around the
bearing
18
.
Installing blade
1. Install blade screw and washers
the hole in the new blade.
2. Line up the blade screw
rectangular fabric
19
with their respective slots in the
hedge trimmer.
3. Mostly tighten the blade screw. Do not tighten fully. Slide
the bottom blade
20
back and forth, and press down
slightly until the blade catches the post
connection rod
22
. Make sure the bottom connection rod
is still in place.
4. Fully tighten the blade screw
5. Place the top connection rod
cam
, angling it around the bearing
23
is faced down toward the top blade
6. Slide the top blade back and forth until the blade catches
the post on the top connection rod.
7. Replace the cover
14
and fasten with the 4 cover screws
12
. Replace the long blade/cover screw and washers
correct order in the hole closest to the blade.
The cutting blades are made from high quality, hardened steel
and with normal usage, they will not require resharpening.
However, if you accidentally hit a wire fence (figure O), stones,
glass, or other hard objects, you may put a nick in the blade.
There is no need to remove this nick as long as it does not
interfere with the movement of the blade. If it does interfere,
remove the battery and use a fine toothed file or sharpening
stone to remove the nick. If you drop the trimmer, carefully
inspect it for damage. If the blade is bent, housing cracked,
handles broken or if you see any other condition that may affect
the trimmer's operation contact your local D
service center for repairs before putting it back into use.
Fertilizers and other garden chemicals contain agents which
greatly accelerate the corrosion of metals. Do not store the unit
on or adjacent to fertilizers or chemicals.
With the battery removed, use only mild soap and a damp
cloth to clean the unit. Never let any liquid get inside the unit;
never immerse any part of the unit into a liquid. Prevent the
blades from rusting by applying a film of light machine oil
after cleaning.
Blade sharpening (Fig. P)
•
KEEP BLADE SHARP FOR BEST PERFORMANCE. A DULL
BLADE DOES NOT CUT CLEANLY.
•
WHEN SHARPENING BLADE, ENSURE THAT BATTERY
IS REMOVED.
REPLacE BEnT OR DaMaGED
BLaDE IMMEDIaTELY
16
, lift the front of
by lifting up on the
17
16
from the old blade into
16
on the new blade and the
21
on the bottom
16
.
17
back onto the eccentric
. Ensure the post
18
.
24
WALT authorized
e
It is recommended that sharpening of blades be performed by
17
and
a D
WALT factory service center. However, blade edges may be
e
sharpened by using a fine tooth file
1. Run trimmer until cutting blades
are offset enough so the guard tooth cannot be touched by
the file. DO NOT file the guard teeth.
2. Be sure the lock-off lever is engaged, the blade has stopped,
and the battery has been removed before sharpening blade.
3. Wear proper eye protection and gloves, and be careful not
to cut yourself.
4. Carefully file the cutting edges of the blade with a fine tooth
file. File toward the cutting edge
angle (38 degrees from horizontal). File only the straight
cutting edges
edge curves into the center of the blade.
5. Flip the trimmer over to sharpen the bottom blade.
6. Repeat steps to sharpen the opposite side of each blade.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.
13
in
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by D
WALT, have not been tested with this product, use
e
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
accessories should be used with this product.
Consult your dealer for further information on the
appropriate accessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
25
.
and guard teeth
26
28
at the original cutting
28
of the blades. Do not file where the cutting
WALT recommended
e
EnGLIsh
27
