UNICOM 802.11b+g User Manual page 30

Channel
Mode
SSID
Tx Power
Change or Apply
WEP
Shows the selected channel that is currently in
use. (There are 14 channels available, depending
on the country.)
Select Mixed Mode or 802.11b only, 802.11g
only standard Mode (If you choose this option
the device will automatically convert the suitable
standard ).
The SSID is the unique name shared among all
points in your wireless network. The name must
be identical for all devices and points attempting
to connect to the same network.
It shows the current SSID setting of the Wireless
USB Adapter.
Select the Tx power from the pull-down menu,
there are four levels including Level 1, Level 2,
Level 3 (Minimum).
Click Change to set the General Connection
Setting. After Completing the setting Click
Apply.
You can select to Enable or Disable the WEP
function by selecting from the pull-down men.
Click Setting and the following figure will
appear.
-
27 -
