UNICOM 802.11b+g User Manual page 20

Tx Rate
Encrypt
More Setting...
Link Status
Signal Strength
Link Quality
Click the down arrow ▼ to select the Tx Rate from Auto, 1, 2,
5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54 Mbps, you can select up to
54 Mbps.
WEP is a data privacy mechanism based on a 64-bit/128-bit
shared key algorithm.
Click the More Setting button to configure, see the following
figure (Refer to the More Setting part on the next page for
more information about this figure)：
Displays the information about the status of the communication
between the Wireless USB Adapter and the Access Point.
Displays the signal strength of the connection between the
Wireless USB Adapter and the Access Point it connects.
Displays the link quality of the connection between the
Wireless USB Adapter and the Access Point it connects.
-
17 -
