- Page 1 Mobility Bases USER MANUAL Lightning Pushchair User Manual & Maintenance Guide for Stealth’s Lightning Pushchair...
- Page 2 Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our mobility bases. You may reach us at: Stealth Products, LLC...
- Page 3 Important Information Important Information! All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be use successfully, you must: ...
-
Page 4: Introduction
They also contain important safety and maintenance information. For further assistance, or more advanced applications, please contact your supplier or Stealth Products at (512) 715-9995 or toll free at 1-800-965-9229. Always keep the operating instructions in a safe place so they may be referenced as necessary. -
Page 5: Warranty
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 6: Table Of Contents
7.1 Safety Rules ......................1 8.0 Design and Function ................2 8.1 Lightning Pushchair Models ................2 8.2 Lightning Standard Series ................3 8.3 Lightning Standard and Special Edition Series ........4 8.4 Lightning Special Edition Series ..............5 8.5 Special Edition Only Features................6 9.0 Technical Data .................. - Page 7 Table of Contents 11.0 Installing Accessories ................. 14 11.1 Headrest Extension ..................14 11.2 Canopy ......................14 11.3 Padded Headrest ..................14 11.4 Heel Loop and Ankle Cuffs ............... 15 11.5 Padded Harness Covers ................15 11.6 Trunk Support ....................16 12.0 Work ‘N Play Tray ................
-
Page 8: Warning Labels
SAFETY necessary. Limited Liability Stealth Products, LLC accepts no liability for personal injury or damage to property that may arise from the failure of the user or other persons to follow the recommendations, warnings, and instructions in this manual. Testing Initial setup and driving should be done in an open area free of obstacles until the user is fully capable of driving safely. -
Page 9: Safety Rules
Safety Rules Safety Rules WARNING Failure to follow these warnings and assembly instructions could result in serious injury or death. Immediately discard any plastic wrapping. Never allow children to fold, assemble, or disassemble the pushchair. Do not go over the weight capacity for the pushchair. Excessive weight may cause a hazardous, unstable condition if the approved load is exceeded. -
Page 10: Design And Function
Design and Function Lightning Pushchair Models The Lightning is a lightweight, highly functional pediatric mobility base designed with a recreational look that compliments today’s lifestyle. The Lightning is an innovative vehicle specifically constructed to be extremely rugged and especially convenient for transporting and storing due to its easy to operate standing and fold feature. -
Page 11: Lightning Standard Series
Design and Function Lightning Standard Series Heavy duty upholstery includes moldable stiffeners and is easily cleaned. Seat depth adjustable to Back angle adjustment accommodate for growth. of 85°, 90° & 95° Offset arms provide additional width. Wheel Locks Storage Basket... -
Page 12: Lightning Standard And Special Edition Series
Design and Function Lightning Standard and Special Edition Series Standard and Special Edition Model: The Standard and the Special Edition models come in three different sizes (11”, 14” and 16”) and two different color options, Red Glow or Navy Blue. 11”... -
Page 13: Lightning Special Edition Series
Design and Function Lightning Special Edition Series Special Edition Model: The Special Edition model comes in three different sizes (11”, 14” and 16”) and two different color options, Red Glow or Navy Blue. The Special Edition has all of the options of a standard model Lightning plus additional add-ons such as: ... -
Page 14: Special Edition Only Features
Design and Function Special Edition Only Features Canopy Padded Covers for Harness Heel-Loop/ Ankle Cuffs Headrest Extension* & Headrest Pad* Adjustable Single* & Double* Flap Lateral Support with Scoli Pad All options are available for standard chairs at an additional charge. -
Page 15: Technical Data
Technical Data Specifications for all Lightning Models Specifications 11” Model 14” Model 16” Model Overall Height (Push Handle) 36” 36” 38” Overall Width 19.5/495.3mm 24”/609.6mm 25” Seat Angle Settings 30° 30° 30° Seat Depth 10” to 12” 12” to 14” 16”... -
Page 16: Adjustments And Functioning
Adjustments & Functioning 10.0 Setting Up and Adjusting the Pushchair 10.1 Grasp the pushchair handles with both arms, and depress the folding locking mechanism with your foot. Hold in the down position and push the back forward toward the seat. ... -
Page 17: Seat Back Angle Adjustment
Adjustments & Functioning 10.0 Seat Back Angle Adjustment 10.2 To adjust back angle, you must remove back upholstery: Remove the top Velcro strap. Remove the bottom Velcro strap. Remove both left and right side of backrest tubes. ... -
Page 18: Seat Back Adjustment
Adjustments & Functioning 10.0 Seat Back Adjustment 10.3 Using a 10mm wrench, remove the adjustment nut on both sides. Move to the desired angle position and fasten the nuts with the 10mm wrench. Seat Depth Adjustment 10.4 LT14 Adjustment= 12”-14”... -
Page 19: Footrest Height Adjustment
Adjustments & Functioning 10.0 Footrest Height Adjustment 10.5 LT14 Adjustment= 1”-17” (25.4-431.8mm) LT11 Adjustment= 1”-12” (25.4-304.8mm) Remove the locking pin Move the footrest to the desired height location. Replace the locking pin Footplate Adjustment 10.6 The footrest will swing-away for easy use and adjustment. -
Page 20: Adjusting And Using The Safety Harness
Adjustments & Functioning 10.0 Adjusting and Using the Safety Harness 10.7 Adjusting the depth of the crotch strap: With the button facing up, guide the strap through the mid section of the holder. Guide the strap under and over the crotch strap ring. -
Page 21: Brake System
Adjustments & Functioning 10.0 On the front of the pushchair, remove the top strap pins and place them where needed. Once the desired location is met, replace both hand nuts and firmly tighten. Locking and unlocking the safety harness: ... -
Page 22: Installing Accessories
Installing Accessories 11.0 Headrest Extension 11.1 Insert the headrest extension rods into the backrest accessory tubes. Canopy 11.2 Insert the accessory tubes or (if headrest extension is in place) insert into headrest extension tube. Padded Headrest 11.3 The headrest extension is required for installation of the headrest pad. -
Page 23: Heel Loop And Ankle Cuffs
Installing Accessories 11.0 Heel Loop and Ankle Cuffs 11.4 Guide the screw from the ankle cuff through the top of the footrest. On the bottom of the footrest, place the washer and fasten the nut. Padded Harness Cover 11.5 ... -
Page 24: Trunk Support
Installing Accessories 11.0 Trunk Support 11.6 Place the trunk support on the front of the pushchair and fasten it around the back set using the Velcro straps. On both sides, wrap the Velcro straps around the lower armrest tube. ... -
Page 25: Work 'N Play Tray
Work ‘N Play Tray 12.0 Attaching the Work ‘N Play Tray 12.1 Contents: Plastic Tray 2 Locking Pins To attach and remove the Work ‘N Play tray to the Lightning pushchair: Place the tray on top of the armrest handles as shown in Figure 1. Insert a locking pin into both sides as shown in Figure 2. -
Page 26: Transporting Instructions
Transportation Instructions 13.0 Preparing Lightning for Transport 13.1 Check that the child is correctly strapped in the seat using the 5-point harness. (Check that the 5-point is properly adjusted) During transportation, the headrest extension must be fitted. Remove the following if fitted: - Work ‘N Play - Rain-hood... -
Page 27: Assembly Instructions
Transportation Instructions 13.0 Assembly Instructions 13.3 Separate the 4 through clamps from the handle threaded clamp by removing the four screws. Apply adequate amount of Loctite to each screws. Loosely position the handle threaded clamp and the through clamps to the front left and right bars as shown: - LT14 (Figure 1) - LT11 (Figure 2) -
Page 28: Attach The Lightning Pushchair To Vehicle
Transportation Instructions 13.0 Attach the Lightning Pushchair to Vehicle 13.4 Position the assembly correctly in the vehicle over the floor track with the front of the Lightning facing towards the front of the vehicle (in the direction of travel). ... -
Page 29: Repairs
Repairs 14.0 Front Wheel Assembly 14.1 Required items: Wheel Washer Shoulder Bolt 10mm Wrench Insert the shoulder bolt from outside the wheel caster, through the wheel and to the inside of the wheel caster. ... -
Page 30: Rear Wheel Assembly
Repairs 14.0 Rear Wheel Assembly 14.2 Required items: Wheel Washer Shoulder Bolt 10mm Wrench Insert the shoulder bolt from the outer part of the wheel, through the wheel, and to the inside wheel mount. ... -
Page 31: Replacing/Removing The Back Upholstery
Repairs 14.0 To replace the back upholstery: Remove the top Velcro strap. Remove the lower Velcro strap. Remove both left and right side backrest tubes. Slip the upholstery out of the tubes. For reassembly, follow steps in reverse order. -
Page 32: First Time Use
First Time Use 15.0 Dealer Assistance 15.1 During first time use by the client, it is advised that the dealer or service technician assists and explains the configuration to the customer (the user and/ or the attendant). If needed, the dealer can make final adjustments. WARNING The Lightning pushchair should only be prescribed and fitted by qualified healthcare professionals. -
Page 33: Cleaning And Maintenance
Cleaning and Maintenance 16.0 Cleaning and Maintenance 16.1 Frame: Wipe with a damp cloth and dry thoroughly on a daily basis. Never put away wet. For stains, wipe with a damp cloth and warm, soapy (mild soap) water. ... - Page 34 NOTES 17.0...
- Page 35 NOTES 17.0...
- Page 36 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 P91D420 Revision Date 2019-12-18...
