AXIOM
Quick Reference Guide
™
Mounting Dimensions
(See Appendix E for dimensions with Universal Mounting Bracket (UMB))
Wiring Base Label
Use the diagrams on the wiring base label to determine the proper connections
for power, trigger, tachometer, communications and I/O (pgs. 51-60).
AXIOM Control Panel
Use the AXIOM control
panel to monitor operational
status including trigger,
communications and read
quality (pgs. 120-121,
140-141).
Mounting Footprint
Range of Motion with UMB
AXIOM Orientation to
Bar Code Scanning Area
(See pg. 21, 97-102)
Need further assistance?
Contact Accu-Sort Technical Support:
ACCU-SORT
SYSTEMS, INC.
®
511 School House Road
Telford, PA 18969
1-800-BAR-CODE
™
info@accusort.com
www.accusort.com
© 2003, 2009 Accu-Sort Systems, Inc. All rights reserved.
ACCU-SORT, 1-800-BAR-CODE, AXIOM and the AS
logotype are trademarks or registered trademarks of
Accu-Sort Systems, Inc.
Accu-Sort reserves the right to change specifications
without notice.
PN 1000069032 R10 | CMS 09-0024 | 2009.08.27 LSM
