Light My Bricks: LEGO Hogwarts Great Hall
75954 Lighting Kit
The following page is the instructions for the
Light My Bricks LEGO Hogwarts
Great Hall (75954) LED light kit.
If you run into any issues, please refer to the
online troubleshooting guide.
To ensure a trouble-free installation of your light kit, please read and follow
each step carefully. These instructions can be downloaded in PDF format
here
Please note: This page lists instructions for the LED light kit only. If you are
wishing to purchase the Light My Bricks LEGO Hogwarts Great Hall (75954) LED

Advertisement

loading
Need help?

Need help?

Do you have a question about the 75954 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LIGHT MY BRICKS 75954

  • Page 1 These instructions can be downloaded in PDF format here Please note: This page lists instructions for the LED light kit only. If you are wishing to purchase the Light My Bricks LEGO Hogwarts Great Hall (75954) LED...
  • Page 2: Package Contents

    light kit , please click here to view the product page Package Contents: 8x White 30cm Bit Lights 4x White 15cm Micro Bit Lights 3x Green Strip Lights 1x White Strip Light 1x Flicker Effects Boards 1x Micro 4-Port Expansion Board 2x 6-Port Expansion Boards 2x 5cm Connecting Cables 3x 15cm Connecting Cables...
  • Page 3 Laying cables in between and underneath bricks Cables can fit in between and underneath LEGO® bricks, plates, and tiles providing they are laid correctly between the LEGO® studs. Do NOT forcefully join LEGO® together around cables; instead ensure they are laying comfortably in between each stud.
  • Page 4 Incorrectly inserting the connector can can result in bent pins inside the port or possible overheating of the expansion board when connected. Connecting cable connectors to Strip Lights Take extra care when inserting connectors to ports on the Strip Lights. Connectors can be inserted only one way.
  • Page 5 When installing Bit Lights under LEGO® pieces, ensure they are placed the correct way up (Yellow LED component exposed). You can either place them directly on top of LEGO® studs or in between. OK, Let’s Begin! 1.) We will begin with installing spot lights to the exterior of the Great Hall. First, take out the following provided LEGO pieces to make up an angled spot light.
  • Page 6 Take a Green Strip Light and using it’s adhesive backing, stick it onto the base of the black 1×6 plate for the spot light...
  • Page 7 2.) Repeat the previous step to build another 3 spot lights using provided pieces and Green Strip Lights as per below: 4x Black Plate 1×6 2x Black Tile 1×1 with Clip 2x Black 1×1 Modified Plate Rounded with Handle 2x Green Strip Lights...
  • Page 8 3.) Take a 15cm Connecting Cable and connect it between two of the spot lights, then take a 30cm Connecting Cable and connect one end to the right strip light as shown below: Connect the two spot lights to the front of the great hall in the below positions, then tuck the 15cm connecting cable underneath the base of the hall.
  • Page 9 Hide the 30cm cable in between the spot lights underneath the base of the hall as shown below.
  • Page 10 5.) Take the AA Battery Pack and insert 3x AA Batteries to it. Connect the battery pack cable to the left port on the spot light on the left of the Hall. Turn ON the battery pack to test the spot lights are working OK. 6.) Take a new 15cm Connecting Cable and connect it to the third green Strip Light.
  • Page 11 Disconnect the lamp from Hagrid, then disconnect the trans yellow round brick from inside. 7.) Take a White 30cm Bit Light and thread the connector end of the cable through the bottom of the trans yellow round brick (larger hole). Thread it all the way through the brick, then slightly bend the LED component so that it is...
  • Page 12 facing down before you pull the cable all the way out from the other side. Thread the connector end of the bit light through the inside of the lamp then all the way out before reconnecting the trans yellow round brick inside.
  • Page 13 Note: If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues on our online troubleshooting guide.
  • Page 14 8.) Disconnect the lamp from the boat and disassemble as shown below: Take a White 30cm Bit Light and bend the cable into a hook with the Bit Light facing out. Thread the Bit Light inside the trans bright yellow brick, then bring the cable to the top and loop it around the stud on top before reconnecting it to the gold tile with clip.
  • Page 15 9.) Pull the cable down the front of the lamp post then loop it underneath the base before reconnecting it to the boat.
  • Page 16 Connect the bit light into the next port on the 6-port expansion board, then tuck the cable underneath the base of the castle. Turn the AA Battery Pack ON to test the boat light is working OK.
  • Page 17 Note: If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues on our online troubleshooting guide.
  • Page 18 Thread the cable back underneath and up the space which leads to the gap on the second floor. Pull the cable all the way out. 11.) From the front of the set, lift up the two side roof sections above the front door.
  • Page 19 Connect the other end of the 30cm connecting cable to a new 6-Port Expansion Board...
  • Page 20 12.) Take a 5cm Connecting Cable and connect it a White Strip Light. Take a 15cm Connecting Cable and connect one end to the other port on the White Strip Light. Connect the other end of the 5cm Connecting Cable to the 6-port Expansion Board we just installed.
  • Page 21 Peel off the White Strip Light’s adhesive backing, then bring it underneath the centre (right side) and stick the strip light underneath this centre section as shown below. Pull the other end of the 15cm Connecting Cable from the strip light out from the other side (left side).
  • Page 22 Turn the AA Battery Pack ON to test the white strip light is working OK. 13.) Remove the entire roof off the great hall at each side as shown below, then thread the other end of the 15cm Connecting Cable from previous step through the archway nearby.
  • Page 23 Secure the dangling cable from the inside of the tower ground floor by connecting it underneath the base plate of the second floor as shown below:...
  • Page 24 14.) We will now light the tower section of the set, starting with the ground floor. We will be using trans clear 2×2 with rounded bottom plates to secure bit lights to the roof of each floor. First take a White 30cm Bit Light and thread the bit light through the top where the front entrance roof is.
  • Page 25 Bottom 2×2 and place the LED component of the Bit Light in the centre of the plate. Ensuring the bit light is facing down, connect the trans clear plate to the roof of the ground floor in the below position:...
  • Page 26 Bring the other end of the Bit Light cable over and tuck it into the side of the roof section. Connect it to the 6-port expansion board above the front entrance, then turn the AA Battery Pack ON to test the ground floor light is working OK. Note: If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).
  • Page 27 15.) We will now light the second floor of the tower. First disconnect the top section just above the second floor using a LEGO Removal Tool, then place the top section onto it’s front so we can access underneath. Take a White 30cm Bit Light and with the cable facing the right, place the LED underneath this section in the centre position as shown below.
  • Page 28 LED is facing down, secure it in place by connecting a provided Trans Clear Plate w Rounded Bottom 2×2 over the top. 16.) Lay the cable down in between the indent, then reconnect the tower on top of the second floor. Bring the cable from the bit light down the right side of the tower and connect it to the next available port on the 6-port Expansion board.
  • Page 29 Note: If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues on our online troubleshooting guide.
  • Page 30 Take a White 30cm Bit Light and with the cable facing the right, place the LED underneath this section in the middle position as shown below. Ensuring the LED is facing down, secure it in place by connecting a provided Trans Clear Plate w Rounded Bottom 2×2 over the top.
  • Page 31 18.) Lay the cable down in between the following indent, then reconnect the tower on top of the second floor. Bring the cable from the bit light down the right side of the tower and connect it to the next available port on the 6-port Expansion board.
  • Page 32 verify where the fault lies (with the light or expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues on our online troubleshooting guide. 18.) We will now install a spot light inside the roof section to shine up onto an object.
  • Page 33 19.) Take out the following provided pieces, then build them into a spot light as shown below: Black Tile 1×1 with Clip Black 1×1 Modified Plate Rounded with Handle Black Plate 1×2 modified with stud jumper Take a provided Black Round Plate 1×1 with open stud and thread the connector end of a White 30cm Bit Light through the base of it (larger hole).
  • Page 34 20.) Connect the top of the black round stud to the spot light we assembled earlier, then thread the cable through the space of the plate with handle. Pull the cable all the way out from the back of the spot light, then connect the spot light in the following position so that it is pointing up to the Owl.
  • Page 35 21.) Pull the right side of the roof out, then thread the cable from the spot light we installed inside the tower and through the gap on the right side. Thread it all the way through and pull it out from the gap in between the back and right roof section.
  • Page 36 If you prefer the spotlight to shine up onto the mirror of erised, connect the spot light to the brown brick in front as shown below: 22.) Bring the cable from the spot light down the right side of the tower and connect it to the remaining port on the 6-Port Expansion Board.
  • Page 37 Neaten the cables going down the side of the tower by first grouping the three cables together at the bottom of the tower. Slightly disconnect the dark tan plate on the right corner, then tuck the three cables underneath and pull the cables up from the other side to eliminate excess cables from the outside of the tower.
  • Page 38 23.) Bring all the cables and expansion board inside the front entrance roof section. Ensure the cables are brought through the right side of the dark grey plate. Neaten up the cables by twisting/folding them around each other a few times to form a neat bunch.
  • Page 39 Secure the cables running down the side of the tower using sticky tape. 24.) Take 2x Adhesive Squares and stick them to the back of the 6-Port Expansion Board at the bottom of the tower. Mount the expansion board to the base of the ground floor underneath the stair case, then secure the cables underneath the dark grey tile as shown below:...
  • Page 40 25.) We will now light up the fireplace and candles inside the great hall. First disconnect the following table, then follow the images below to disconnect sections to remove the entire fire place.
  • Page 41 Remove the following black brick from the fireplace, then take a White 30cm Bit Light and with the cable facing the back, place it over the right stud, where the flame was connected to. Disconnect the flame piece from the black round plate, then use this round plate to secure the Bit Light down.
  • Page 42 26.) Repeat the previous step to install another White 30cm Bit Light to the stud on the left, then while ensuring both cables are laid in between the brown studs behind, reconnect the black piece we removed earlier, along with the surrounding fireplace hood section.
  • Page 43 Take the two flame pieces and carefully snip off the tip ends of each piece using a pair of scissors. This will allow us to then reconnect them to the black round plates with bit lights underneath. 27.) Take the two cables from behind the fireplace and thread them up the following gap in the ceiling.
  • Page 44 Secure the two cables in between studs underneath the following angled roof brick, then pull the cables back inside as shown below:...
  • Page 45 28.) Reconnect the left roof section above the entrance, then bring the 15cm connecting cable from this side across to the right and connect it to the IN port on the Flicker Effects Board.
  • Page 46 Take the two Bit Light cables from the fireplace and connect each cable to the OUT ports on the Flicker Effects Board. Turn ON the AA Battery Pack to test the fireplace lights are working OK with the flicker effect. Note: If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light, expansion board, or effects board).
  • Page 47 29.) We will now light up the candles on the roof. First disconnect this section by pulling them out at the technic brick holes, then disconnect the candle and flame pieces as shown below:...
  • Page 48 Take out a White Micro 15cm Bit Light and carefully bend the LED back as shown in the below image. Thread the Bit Light into the hole of the candle piece as shown below, then reconnect the flame piece. We want the LED to be as close to the flame tip as possible therefore, threading the cable all the way to the end of the hole is not necessary.
  • Page 49 30.) Reconnect the candle to the roof frame, then repeat previous process to install another 3x White Micro 15cm Bit Lights to the remaining 3x candles.
  • Page 50 31.) Reconnect the candle frame section to the Great Hall roof, then thread each candle light cable through the following holes of the black technic brick above.
  • Page 52 32.) Connect each Micro Bit Light to the ports on the Micro 4-Port Expansion Board. Ensure you follow the below images to ensure you are connecting the light cables into each port correctly.
  • Page 53 Take a 5cm Connecting Cable and connect it to one of the larger ports on the Micro 4-Port Expansion Board. Connect the other end of the connecting cable to the remaining OUT port on the flicker effects board. Turn the AA Battery Pack ON to test the candle lights are working OK with the flickering effect.
  • Page 54 verify where the fault lies (with the light, expansion board, or effects board). To correct any issues with expansion board ports, please view the section addressing expansion board issues on our online troubleshooting guide. 33.) Turn the set over to the front, then take 4x Adhesive Squares and stick two to the back of the Flicker Effects Board, and another two to the back of the Micro 4-Port Expansion Board.
  • Page 55 bit light cables toward the right side as shown below. Do your best prevent any wiring from dangling down and being seen from the inside of the hall. The last step is to reconnect the main roof section.
  • Page 56 This finally completes installation of the Light My Bricks Hogwarts Great Hall Light Kit. We thank you for purchasing this product and hope you enjoy!
