Dynex DX-TRP61BL Quick Setup Manual

Storing your tripod
1 Remove your camera.
2 Loosen the center column set screw. Lower the column as far as
it will go, then tighten the set screw.
3 Collapse the legs.
4 Pull out the angle adjusting tabs and push the legs in.
5 Store the tripod in the carrying case.
Important safety instructions
• Make sure that all leg locks are correctly tightened and that the
legs are fully opened before use.
• Do not carry or transport your tripod with camera equipment
attached (for example, over your shoulder or cradled in your
arms).
• Do not expose your tripod to excessive heat or cold, or use near
any flame or fire.
• Do not oil or grease any part of the tripod.
• Do not use any solvents or thinners to clean your tripod. Use
only a mild detergent and wipe dry with a soft, lint-free cloth
only.
• Do not exceed the load limit of this tripod.
Specifications
• Maximum operating height: 61 in. (157.5 cm)
• Minimum operating height: 17.3 in. (44 cm)
• Folded height: 22.4 in. (57 cm)
• Net weight: 3.0 lbs (1.4 kg)
• Max operating load: 6.6 lbs (3 kg)
• Number of leg sections: 4
• Quick release thread: 1/4 in. (0.6 cm)
• Panoramic angle: horizontal: 360° and vertical: 90°
• Material: aluminum alloy
One-year limited warranty
Visit www.dynexproducts.com for details.
Contact Dynex:
For customer service, call 800-305-2204 (U.S. and Canada) or
01-800-926-3020 (Mexico)
www.dynexproducts.com
DYNEX is a registered trademark of BBY Solutions, Inc.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2014 BBY Solutions, Inc. All Rights Reserved.
V1 ENGLISH 14-0370
DX-TRP61BL
61" Eco-Pro Tripod
Before using your new product, please read
these instructions to prevent any damage.
QUICK SETUP GUIDE
