5 + 5 Storage and Tray Cabinet
Model# ELR-17255
WARNING:
Adult Assembly Required.
Two adults recommended.
- Contains small parts, sharp points and edges.
- Do not stand, sit, kneel, climb, lean or pull on unit for support.
- Never leave children unattended.
- Do not place unit near high heat or moisture.
- Adult supervision recommended.
Children climbing on furniture
can lead to death or serious
injury due to tipping secure unit
to wall using appropriate
hardware
TOOLS INCLUDED
TOOLS NEEDED
Hex Tool (1)
Phillips Screwdriver
BEFORE ASSEMBLING, MAKE SURE YOU HAVE ALL THE PARTS
A
A1
A2
B
C
D
E
Parts List
Upper DIvider (4)
Left & Right
F
Side Panels (1/1)
Top Panel (1)
H
Upper Shelf (1)
I
Lower Shelf (1)
J
K
Bottom Shelf (1)
K1
L
Batch ID Sticker
L1
located on underside
Lower Divider (3)
G
Upper Back Panel (1)
Lower Back Panel(2)
Hex Screws (30)
Use the
Hex Tool
Cam Posts & Cam Locks (14/14)
K2
Use a Phillips
Screwdriver
Phillips Screws and Casters (16/4)
L2
Use a Phillips
Screwdriver
